Key Sequence
The following example shows how either bits or timers can be controlled with
the Force Set/Reset operation. The displays shown below are for the follow-
ing program section.
0200 LD 0002
0201 TIM 00
# 0123
0202 LD TIM 00
0203 OR 0501
0204 AND NOT 0003
0205 OUT 0501
TIM 00
SV
0002
TIM 00
0501
0501
0003
Address Instruction Operands
Example
Monitoring Operation and Modifying Data Section 7-3
