A - 13
Appendices
NX-series Communications Interface Units User’s Manual (W540)
A-3 List of NX Objects
A
A-3-2 NX Objects for the NX-CIF101 and NX-CIF105
This section lists other objects.
• The following table gives the meanings of the set valu
es for the Ch1 Transmission Buffering
Enable/Disable Setting.
• The following table gives the meanings of the set values for the Ch1 Baud Rate.
*3. This is the value of the RS signal when communications are in the Operational state or immediately
after restarting the port. This item is invalid when the flow control method is set to RS/CS flow control,
and the initial RS signal value will always be ON. If the Initial RS Signal Value is set to OFF, use the RS
Signal ON control command to turn ON the RS signal.
Other Objects
Index
(hex)
Subindex
(hex)
Object name Default Data range Unit
Data
type
Access
I/O allo-
cation
Data
attri-
bute
5000 --- Transmission Buffering
Enable/Disab
le Setting
--- --- --- --- --- --- ---
01 Ch1 Transmission Buffer-
ing Enable/Disable Setting
1 0 or 1 --- USINT RW No Y
Set value Description
0 Disabled
1 Enabled
Index
(hex)
Subindex
(hex)
Object name Default Data range Unit
Data
type
Access
I/O alloca-
tion
Data
attri-
bute
5001 --- Baud Rate --- --- --- --- --- --- ---
01 Ch1 Baud Rate 3 0 to 8 --- USINT RW No Y
Set value Description
0 1,200 bps
1 2,400 bps
2 4,800 bps
3 9,600 bps
4 19,200 bps
5 38,400 bps
6 57,600 bps
7 115,200 bps
8 230,400 bps
Index
(hex)
Subindex
(hex)
Object name Default Data range Unit
Data
type
Access
I/O alloca-
tion
Data
attri-
bute
5002
*1
*1. Only the NX-CIF105, which has an RS-422A/485 port, has this object. This object does not exist in the NX-CIF101.
--- Signal Wire --- --- --- --- --- --- ---
01 Ch1 Signal Wire 1 0 or 1 --- USINT RW No Y
