Appendices
A - 12
NX-series Communications Interface Units User’s Manual (W540)
• The meaning of the Output Sub Info is different between when the Change Number of Characters to
Determine the End control command is specified in the Output Data Type and when the Change
Communications Setup control command is specified.
a) The following table gives the Output Sub Info when
the Change Number of Characters to Deter-
mine the End control command is specified.
b) The following table gives the Output Sub Info when
the Change Communications Setup control
command is specified. If any of the set values is out of range, 0003 hex (setting out-of-range
error) is returned in the Input Sub Info from the CIF Unit.
Bit Item name Description
00 to 15 Number of Characters to
Determine the End
The value specified for the number of characters
to determine the
end.
*1
Setting range: 0000 to 2710 hex (0 to 10,000 decimal)
The number of characters to determine the end is not set if 0000
he
x is
specified.
Unit: 0.1 character
*1. For example, if 0064 hex (100 decimal) is specified, the number of characters to determine the end is
10.
Bit Item name Description
00 to 03 Baud Rate [bps] 0 hex: No change
1 hex: 1,200
2 hex: 2,400
3 hex: 4,800
4 hex: 9,600
5 hex: 19,200
6 hex: 38,400
7 hex: 57,600
8 hex: 115,200
9 hex: 230,400
04 to 05 Data Length [bits] 0 hex: No change
1 hex: 7
2 hex: 8
06 to 07 Parity 0 hex: No change
1 hex: No parity
2 hex: Even
3 hex: Odd
08 to 09 Stop Bits [bits] 0 hex: No change
1 hex: 2
2 hex: 1
10 to 11 Flow Control Method 0 hex: No change
1 hex: No flow control
2 hex: RS/CS flow control
*1
3 hex: Xon/Xoff control
*1. The NX-CIF105 port is RS-422A/485. You cannot use RS/CS flow control. If you specify RS/CS flow
control for the NX-CIF105, a setting out-of-range error (0003 hex) will occur.
12 to 13
Flow Control Target
*2
*2. This item is not valid when no flow control is set.
0 hex: No change
1 hex: Transmission and reception
2 hex: Transmission
3 hex: Reception
14 to 15
Initial RS Signal Value
*3
0 hex: No change
1 hex: ON
2 hex: OFF
To Next Page
