A - 11
Appendices
NX-series Communications Interface Units User’s Manual (W540)
A-3 List of NX Objects
A
A-3-2 NX Objects for the NX-CIF101 and NX-CIF105
22 Change Communications
Setup
Changes the communications setup to the values specified
in the Output Sub Info.
*2
31
Start One-shot Monitoring
*4
Sets the monitor type of the serial line monitor to one-shot
monitoring and starts data monitoring.
32 Start Continuous Monitor-
ing
*3
Sets the monitor type of the serial line monitor to continuous
monitoring and starts data monitoring.
33
Stop Monitoring
*5
Stops serial line monitoring.
34 Clear Serial Line Monitor
Buffer
*6
Clears the buffer for the serial line monitor.
*1. If you attempt to execute this command for the NX-CIF105, execution is not possible and the command
ends in an error.
*2. These commands are valid only when the flow control setting is not set to RS/CS flow control. If you at-
tempt to execute this command when the flow control setting is set to RS/CS flow control, execution is not
possible and the command ends in an error.
*3. The new value is applied after the port is restarted.
*4. If this command is executed while monitoring is in
progress, monitoring is continued and the command
ends normally.
*5. If this command is executed while monitoring is stopped, monitoring remains stopped and the command
ends normally.
*6. This command is valid only while monitoring is stopped. If you
attempt to execute this command while mon-
itoring is in progress, execution i
s not possible and the command ends in an error.
Command
