4 Installation and Wiring

4 - 8

NX-series Communications Interface Units User’s Manual (W540)

This section describes how to connect and remove wires.

 Terminal Block Parts and Names

 Required Tools

Use a flat-blade screwdriver to connect and remove wires.

Use the following flat-blade screwdriver.

Recommended screwdrive

Connecting/Removing Wires

Model Manufacturer

SZF 0-0,42,5 Phoenix Contact

Terminal hole

Release hole

2.5 mm0.4 mm

Front view

8 to 12

Side view

2.5-mm dia.
