2 Electromagnetic Inductive RFID System V640 for Semiconductor Industry
■ Long-range Communications Model
Note: 1. Use of the V700-L11 ID Link Unit enables the Amplifier Unit to be removed/installed while the CIDRW System remains turned ON in the
event of a malfunction or during maintenance.
2. Use the V700-L22 CIDRW Controller when using SECS communications protocol.
3. Refer to the User’s Manual (V640-HAM11-V2: Cat. No. Z167; V640-HAM12: Cat. No. Z218) for details.
ID Tag
V640-HS62
CIDRW Head
V640-HAM12
Amplifier Unit
V700-L22
CIDRW Controller
RI-TRP-DR2B
RI-TRP-WR2B
(32-mm Glass
Transponder)
Texas
Instruments
RS-485 host device
via ASCII protocol
RS-232C host device
via SECS I/II protocol
RS-232C host device
via dedicated 1:1
protocol
RS-232C host device
via ASCII protocol
