4 Electromagnetic Inductive RFID System V640 for Semiconductor Industry
Specifications
■ CIDRW Head
■ Amplifier Unit
Item
Transmission frequency 134 kHz
Insulation resistance 20 M
Ω min. (at 100 VDC) between the connector terminals and the case
Dielectric strength 1,000 VAC (50/60 Hz, 1 minute) between the connector terminals and the case (leakage current: 5 mA
max.)
Vibration resistance
10 to 150 Hz, 0.20-mm double amplitude, 15-m/s
2
acceleration with 10 sweeps of 8 min each in X, Y, and
Z directions
Shock resistance
150-m/s
2
acceleration for 3 times each in X, Y, and Z directions (18 times in total)
Ambient operating temperature 0 to 40°C (with no icing)
Ambient operating humidity 35% to 85% (with no condensation)
Ambient storage temperature
−15 to 65°C (with no icing)
Ambient storage humidity 35% to 85% (with no condensation)
Degree of protection IEC60529: IP20
Cable 2-m (3-mm dia.) coaxial cable 1.9-m (3-mm dia.) coaxial cable
Case ABS/epoxy resin, stainless-steel mounting fixture
Weight Approx. 70 g Approx. 100 g
V640-HS61
V640-HS62
Item
Host interface RS-232C (via dedicated 1:1 protocol or 1:N protocol) or RS-485
Power supply voltage 24 VDC (max. fluctuation 20.4 to 26.4 VDC)
Power consumption 3 W max.
Insulation resistance 20 M
Ω min. (at 100 VDC) between the power supply terminals and the frame ground terminal
Dielectric strength 1,000 VAC (50/60 Hz, 1 minute) between the power supply terminals and the frame ground terminal (leak-
age current: 5 mA max.)
Vibration resistance
10 to 150 Hz, 0.20-mm double amplitude, 15-m/s
2
acceleration with 10 sweeps of 8 min each in X, Y, and
Z directions
Shock resistance
150-m/s
2
acceleration for 3 times each in X, Y, and Z directions (18 times in total)
Ambient operating temperature 0 to 40°C (with no icing)
Ambient operating humidity 35% to 85% (with no condensation)
Ambient storage temperature
−15 to 65°C (with no icing)
Ambient storage humidity 35% to 85% (with no condensation)
Degree of protection IEC60529: IP20
Case SECC (coated)
Ground Ground at a resistance of less than 100
Ω.
Weight Approx. 500 g Approx. 400 g
V640-HAM11-V2
V640-HAM12
