2 Programmable Relay ZEN
Ordering Information
■ List of models
■ Accessories
Note: Memory Cassettes created using the CPU Unit can be read to the CPU Unit, regardless of which model is used, however the following points
must be taken into consideration.
1. When using a Memory Cassette created with a V1 CPU Unit for a Pre-V1 CPU Unit, use the Memory Cassette within the ranges for the
Pre-V1 CPU Unit's timers, holding timers, counters, weekly timers, calendar timers, and displays.
2. When using a Memory Cassette created with a CPU Unit with 20 I/O points for a CPU Unit with 10 I/O points, use only up to 6 inputs and
4 outputs for the I/O bit area.
Name No. of
I/O
points
Display
type
Power Supply
voltage
Inputs Outputs Buttons,
calendar
& clock
Analog
input
Model number
CPU Units 10 LCD 100 to 240 VAC 6 100 to 240 VAC 4 Relays Yes No ZEN-10C1AR-A-V1
LED No No ZEN-10C2AR-A-V1
LCD 24 VDC 6 24 VDC 4 Relays Yes Yes ZEN-10C1DR-D-V1
LED No Yes ZEN-10C2DR-D-V1
LCD 24 VDC 6 24 VDC 4 Transistors Yes Yes ZEN-10C1DT-D-V1
LED No Yes ZEN-10C2DT-D-V1
20 LCD 100 to 240 VAC 12 100 to 240 VAC 8 Relays Yes No ZEN-20C1AR-A-V1
LED No No ZEN-20C2AR-A-V1
LCD 24 VDC 12 24 VDC 8 Relays Yes Yes ZEN-20C1DR-D-V1
LED No Yes ZEN-20C2DR-D-V1
LCD 24 VDC 12 24 VDC 8 Transistors Yes Yes ZEN-20C1DT-D-V1
LED No Yes ZEN-20C2DT-D-V1
Expansion
I/O Units
8 - 4 100 to 240 VAC 4 Relays - ZEN-8EAR
- 4 24 VDC 4 Relays - ZEN-8EDR
- 4 24 VDC 4 Transistors - ZEN-8EDT
4 - 4 100 to 240 VAC - - - ZEN-4EA
- 4 24 VDC - - - ZEN-4ED
- - - 4 Relays - ZEN-4ER
Name Specifications Remarks Model number
Memory cassette EEPROM (for data
security and copying)
Enables programs and parameter settings to be saved or copied to another
ZEN (See note.)
ZEN-ME01
LCD type LED type
Transfer from ZEN to
Memory Cassette
Supported Not Supported
Transfer from Memory
Cassette to ZEN
Supported Supported (Automatic
transfer when power
turned ON)
Memory Cassette
initialization
Supported Not Supported
Connecting cable 2-m RS-232C (9-pin
sub-D connector)
- ZEN-CIF01
Battery Unit 10 years min. Battery
life (at 25° C)
The program and parameter settings are backed up in the CPU Unit's
internal EEPROM and will not be lost. Use the Battery Unit to prevent
loss of calendar/clock, holding bits, holding timer present values, counter
present values, and other data when the power is turned OFF for an
extended time (for 2 days or more at 25° C). This data is otherwise backed
up using RAM and a super-capacitor.
ZEN-BAT01
ZEN Support Software Runs on Windows 95,
98, 2000, ME, XP or
NT 4.0.
Specifically designed for the ZEN (CD-ROM). ZEN-SOFT01-V3
