3
Overview
Left Y-Axis
Tension Adjustment
Left Y-Axis
Restraining Bolt
X-Axis
Stepper Motor
Left Frame
with Belt
Laser Key and
Emergency Stop Switch
Power Button
Power Connection
USB Control
MicroSD Card Slot
Diagnostic Tool Port
Rotary and
Protective Cover
Connections
Flame Detection
Sensor
Light
Air Assist Fan
Back Frame Right Y-Axis
Tension Adjustment
Right Y-Axis
Restraining Bolt
X-Axis
Restraining Bolt
X-Axis
Tension Adj.
Right Frame
with Belt
Warnings
Support Legs
Front Frame
Air Assist Tube
Laser Module
Protective Shield
Locking Lever
X-Axis Gantry
