on MICROWAVE 10 - Microwave Oven Operation; Microwave Oven Installation

7
English
Microwave oven:
1. Control panel
2. Turntable shaft
3. Turntable ring assembly
4. Glass tray
5. Observation window
6. Door
7. Safety interlock system
Install the microwave oven:
1. Place the microwave oven on a level surface that
provides enough open space for the intake and outlet
vents. The minimum installation height is 85 cm. The
rear of the microwave shall be placed against a wall with
a minimum clearance of 30 cm above and a minimum
clearance of 20 cm on the sides.
Note: Do not place the microwave oven close to a heat
producing appliance, this could create damage.
2. Connect the power cable to a wall outlet. Make sure the
voltage and the frequency of the wall outlet is the same
as the voltage and the frequency on the rating label on
the microwave oven.
Overview Operation
1
2
3
45
6
7
20cm
30cm
20cm
min85cm
0cm
