4 of 6
ASSEMBLY INSTRUCTION (50-SH0105)
STEP 2
Using fourteen Screws (1), continue attaching the other four Shelves (C) and three Middle Boards (B) until all
are attached. With the remaining two Screws (1) attach the other End Board (A) to the last Shelf (C).
STEP 3
Push the twenty Screw Caps (4) securely onto the screw heads.
STEP 1
side facing you and place it to the right of the End Board as shown. Using two Screws (1) screw the boards
together with the Allen wrench (5). Then, attach one Middle Board (B) to the Shelf (C) using two Screws (1).
#1 x 4 Pcs
B
C
A
A
C
C
B
#1 x 16 Pcs
#4 x 20 Pcs
#5
#5
To Next Page
