Onfloor SWOOP User Manual

PAGE 11
MOTOR & CHASSIS ASSEMBLY PARTS LIST
Ref
No
Part Description Qty
Part
No
1 5 HP Motor Assembly 3 240028
2
5
/ 8 ”X 1
1
/ 2 ” Grip Range Pin w/Ring 1 216216
3 Lift Handle 3 490385
4
1
/ 4 ” Split Lockwasher 6 342858
5
1
/ 4 -20 X 1
1
/ 4 ” Socket Head Cap Screw 6 492752
6
3
/ 8 ” -16 X 1
1
/ 2 ” Hex Head Bolt 12 437336
7
5
/ 16 ” X 1” Socket Set Screw 6 475939
8 1
3
/
4 ” X .33” Steel Mounting Pin
12 490458
9 Velcro Strip 1 476048
10 Driver Adaptor 3 475564
11
3
/ 8 ” Split Lockwasher 12 368849
12 #10 10-24 Hex Nut w/Lockwasher 4 337315
13 Steel Washer 4 369519
14 #10 10-24 X
5
/ 8 ” Phillips Screw 4 351210
15
5
/ 16 ” -18 X 1” Hex Head Bolt 16 483249
16 Motor Housing Assembly 1 475505
17 Swivel Caster w/3” Wheel 2 479942
18
5
/ 16 ” Flat Washer 16 363219
19 .31” Lockwasher 16 316113
20 Caster Mounting Bracket 2 215015
Detail A
1 Cap 2 349259
2 #10-24 x .75 Screw 10 337315
3 Retaining Wire 1 479152
4 #10 Lockwasher 6 380725
5 Circle Gasket 2 320986
6 Exhaust Fitting 2 310999
