9
Switch off power and remove plug from power point. If the pump is hard wired
into any other controls such as time clocks or automatic heads etc., THE WIRING
SHOULD BE REMOVED BY A QUALIFIED ELECTRICIAN.
Close control valves and undo barrel unions from suction and discharge lines.
Remove pump and take to your nearest authorised Onga service agent
If the need arises to contact an Onga service agent please have all details
available including model and serial number, date of purchase and
particulars of fault.
If service parts are required please quote Model Number and Type of pump as
shown on the label of the pump.
Removal of Pump for Servicing
PPP-550-1P PPP-750-1P PPP-1100-1P PPP-1500-1P
(405976) (405976) (405977) (405977)
801210 801210 801277 801277
2 BASE 1
3 SCREW M6 x 16mm C/SNK HD Phlps 2
BASE & SCREW KIT (INCLUDES 2&3) 1
800532 800532 800532 800532
4 NUT 5/16inW 4
5 SHAFT SLEEVE 1
6 ORING SHAFT SLEEVE 1
7 YOKE AND LIP SEAL 1
8 SCREW 5/16inW x 3/4in 4
YOKE KIT (INCLUDES 7&8) 1
412050K 412050K 412050K 412050K
9 BAFFLE 1 305300 305300 305300 305300
10 ORING CASING 1
11 MECHANICAL SEAL 1
SEAL KIT (INCLUDES 5,6,10&11) 1
800583K 800583K 800583K 800583K
MECHANICAL SEAL (PACK OF 25) 25 800900 800900 800900 800900
12 DIFFUSER 1 305460 305460 303460K 303460K
13 IMPELLER 1 512750K 507530K 506840K 506820K
14 SEPERATOR PLATE 1 408730 408730 408730 408730
15 CASING ASSEMBLY (INCLUDES 16,17,18&19) 1 801200 801200 801200 801200
16 CASING 1
17 BASKET 1 302310 302310 302310 302310
18 LID 1
19 O-RING LID 1
LID AND O-RING KIT (INCLUDES 18&19) 1 800897K 800897K 800897K 800897K
20 BARREL UNION KIT (INCLUDES 21,22&23 X2) 1 800714 800714 800714 800714
21 TAIL BARREL UNION WHITE 2
22 NUT BARREL UNION WHITE 2
23 O-RING BARREL UNION 2
24 DRAIN PLUG 1
504605 504605 504605 504605
25 BOLT 5/16inW x 1.3/4in 4
FASTENERS KIT (INCLUDES 4&25 X4) 1
801278 801278 801278 801278
See Base and Screw Kit
See Lid & O-Ring Kit
See Casing Assembly
No.
MOTOR11
See Fasteners Kit
See Yoke Kit
See Seal Kit
Description Qty
See Barrel Union Kit
See Fasteners Kit
See Seal Kit
Part Number
