OPERATIONS OPERATIONS
Your split AC operates in one of four modes, COOL-DRY- . The modes button
cyclically chooses between these operating modes.
The AUTO Mode :
1. Press "MODE" button to cyclically step through the AUTO-COOL-DRY-FAN modes and stop
when AUTO mode is selected.
2. symbol can be seen on the Remote panel when you select the AUTO mode.
3. In this mode, the fan speed can be changeable.
0
4. Temperature can be pre-set in this mode, default temperature is 25 C.
5. In the AUTO mode, your AIR CONDITIONER "Thinks” for you.
The unit automatically and continuously monitors the difference between room temp. and
set temp. and adjusts the fan speed accordingly, to ensure maximum comfort.
The COOL mode:
In the cool mode, the compressor is in operation and your AC functions in the standard
operating mode, cooling your room to the desired set temp.
1. Press "MODE" button to cyclically step through the AUTO-COOL-DRY-FAN modes and
stop when cool mode is selected.
2. symbol can be seen on the Remote panel when you select the cool mode.
In this mode, you can change the temp. settings by pressing " " and “ ” temp.
buttons.
You can change the fan speed setting by pressing FAN button.
3. If the Room temp. is more than the set temp., then the compressor & outdoor FAN will
remain ON and perform the Cooling operation. If the room temp. achieves the temp. less
than set temp., then the compressor & outdoor FAN will remain OFF.
The DRY Mode:
In the DRY mode, your AC reduces the humidity within the room faster.
1. Press "MODE" button to cyclically step through the AUTO-COOL-DRY-FAN modes and
stop when DRY mode is selected.
2. symbol can be seen on the Remote panel when you select the DRY mode.
3. In DRY mode, Temperature and FAN Speed cannot change. Default pre-set temperature is
0
25 C. Indoor FAN will run at low speed. Compressor & Outdoor Fan work as per the
Temperature difference.
4. In this mode Horizontal swing is inactive, only Vertical swing is active.
AUTO- FAN
The FAN Mode:
1. Press "MODE" button to cyclically step through the modes and stop
when FAN mode is selected.
2. symbol can be seen on the Remote panel when you select the FAN mode.
3. In FAN mode, only Indoor FAN will run at set speed and Compressor & Outdoor Fan will
remain off. Temperature will be displayed on indoor unit as well as remote. Temperature
setting can be changed.
4. In this mode, you can change the Indoor FAN Speed.
TIMER Operation:
You can program your split AC to switch itself ON or OFF at particular time.
Maximum set time is 24 hrs, with 1.0 hr increment .
ON TIMER:
When the AC is "OFF" (in standby), press "TIMER" Button on remote to use this feature as the
TIMER. (make sure that MCB switch is "ON". The "TIMER" light on Indoor unit will glow ON.
.
For EXAMPLE:
Suppose you want to switch ON the AC after 8 hrs. Press "TIMER" button, when AC is in OFF
condition.
Press "TIMER" button to set ON timer. Display on Remote will show "8”.
OFF TIMER:
When the AC is "ON", press "TIMER" Button on remote to use this feature as
the TIMER. The "TIMER" light on Indoor unit will glow ON.
For EXAMPLE:
Suppose you want to switch OFF the AC after 8 hrs. Press "TIMER" button, when AC is in ON
condition.
Press "TIMER" button to set OFF timer. Display on Remote will show "8”.
CANCEL TIMER:
If you want to cancel either TIMER ON or TIMER OFF, press the TIMER button till the timer
becomes blank.
AUTO-COOL-DRY-FAN
