Onida S18FLT5 User Manual

9 8
OPERATIONS
Turbo MODE:
TURBO-AUTO-COOL-DRY-ECO-FAN modes
and stop when TURBO mode is selected, It
ECO MODE:
selecting
Press Mode Button cyclically step through the
activates the Turbo function and air conditioner
goes to powerful cooling. During this Mode temperature and fan speed cannot be changed.
In this mode the AC works on a preset temperature of 18 degree centigrade at high fan
speed. Compressor will start immediately in this mode and will continue to operate till set
temperature is achieved .Thereafter it will work in cyclical ON/OFF mode to keep the room
temperature within 2 degree of set temperature. Press mode button again to cancel this
operation.
ECO mode on remote activates Energy Saver function to keep room normal
temperature by reducing compressor run hours to get more savings.
In this mode the AC works on a preset temperature of 25 degree centigrade at selectable fan
speed. Compressor will work in cyclical ON/OFF mode to keep the room temperature within 2
degree of set temperature. ( symbol will appear on remote control display).
In this mode temperature cannot be changed & Fan speed can be changed.
Press mode button again to cancel this operation.
Ceiling Fan Manual Operation – only when optional i-cool ceiling fan
controller is installed:
Ceiling fan speed can be controlled only through AC remote control as all other manual
controllers are bypassed while installing i-cool fan controller.
When AC is in any mode other then i-cool mode, Ceiling fan speed can be controlled using
remote control. To enable this Ceiling fan mains have to be in ON position. Press on
remote to start ceiling fan. Ceiling fan speeds can be changed by pressing key on remote
to increase and key on remote to decrease. The speeds can be varied by 5 steps by
pressing keys on remote. Press key on remote till the ceiling fan switch off.
My Favorite Mode:
In this mode user can set personal setting in which, Mode, Set Temp. Fan speed, Swing,
ceiling fan,sleep and OFF Timer can be set as per customer selection.
To set MY FAV mode Press & Hold MY FAV key for 5sec. MY FAV icon will blink, during icon
blinking customer can set all parameter mentioned above, After selection press again the MY
FAV key to register the settings. MY FAV settings done as per selection and AC will work as
per the selection. To come out of MY FAV mode, press again MY FAV MODE key. In this mode
all keys are deactive except MODE & ON/OFF key. When ever to select MY FAV mode again,
just press the My FAV mode key , AC will work as per the selection done previously.
SMART-SLEEP MODE: 123
3 Stage Smart-Sleep with 4 personal preference modes,
To switch on Smart-Sleep operation, press “SLEEP” button on remote and the indoor fan
will run at low speed. Press the same button four times to quit the Smart-Sleep mode.
OPERATIONS
Initial Sleep Stage Deep Sleep Stage Wake Up stage Stage 1
Stage 2 Stage 3
Smart Sleep -Personal Preference mode Normal
Set Temperature - 31ºC - 16ºC
Cools at Set Temp + 1ºC / hour for next 2 hours.
Cools at Set Temp + 2ºC after 2 hours
Cools at Set Temp + 2ºC after 2 hours
Set Temperature - 23ºC - 16ºC
Cools at Set Temp + 1ºC / hour for next 3 hours.
Cools at Set Temp + 3ºC for next 5 hours
Cools at Set Temp + 1ºC after 8 hrs
Set Temperature - 24ºC - 27ºC
Cools at Set Temp + 1ºC / hour for next 2 hours.
Cools at Set Temp + 2ºC for next 6 hours
Cools at Set Temp after 8 hrs
Set Temperature - 28ºC - 31ºC
Cools at Set Temp all along Cools at Set Temp all along Cools at Set Temp all along
Set Temperature - 23ºC - 16ºC
Cools at Set Temp + 1ºC / hour for next 3 hours.
Cools at Set Temp + 3ºC for next 4 hours
Cools at Set Temp + 2ºC after 7 hrs
Set Temperature - 24ºC - 27ºC
Cools at Set Temp + 1ºC / hour for next 2 hours.
Cools at Set Temp + 2ºC for next 5 hours
Cools at Set Temp + 1ºC after 7 hrs
Set Temperature - 28ºC - 31ºC
Cools at Set Temp all along
Cools at Set Temp all along Cools at Set Temp all along
Set Temperature - 23ºC - 16ºC
Cools at Set Temp + 1ºC / hour for next 3 hours.
Cools at Set Temp + 3ºC after 3 Hours
Cools at Set Temp + 3ºC after 3 Hours
Set Temperature - 24ºC - 27ºC
Cools at Set Temp + 1ºC / hour for next 2 hours.
Cools at Set Temp + 2ºC after 2 hours
Cools at Set Temp + 2ºC after 2 hours
Set Temperature - 28ºC - 31ºC
Cools at Set Temp all along Cools at Set Temp all along Cools at Set Temp all along
Bio Sleep -Personal Preference mode 2 Smart Sleep Personal Preference modes
Temperature Set Condition
Bio Sleep -Personal Preference mode 1 Bio Sleep -Personal Preference mode 3
