Product Overview (Cont.)
1 Light sensor
2 Infrared LEDs - back-up light for night vision
3 Camera lens
4 Power LED - illuminates green when the unit is powered
5 Microphone
6 Speaker
7 Pair button - press during the re-registration process (not necessary for
initial use)
8 Temperature sensor
9 Mini USB power adaptor socket - insert the adaptor cord for powering
Camera (Baby) Unit
1
2
6
8
7
9
3
4
5
