3
WARNING
TO PREVENT FIRE OR SHOCK HAZARD
DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE
USE ON LY WITH A 250V FU SE
~ 2 2 0 V / 5 0 H z
AC IN
FUS E 100V - 12 0V: T6.3 AL
220 V - 240V: T3 .15AL
RIGH T LEFT
RIGH T LEFT
SERI AL NO. :
AUX TUNE R
CD
TAPE
OUT
IN
BYPASS
L
R
POWER CO NS UM PT IO N: 1 35 W
STEREO I NT EG RATED AM PL IF IE R
ONIX ENGL AND ELECTRONICS LTD
USB DAC OPTICALBT ANT
MODEL: R A- 12 5
(
21
)
DVD
CD DVD
TUN ER AUX
TAPE B YPAS S U SB BT
OPT ICAL
STER EO I NTE GR ATE D AMP LIF IE R RA- 125
VOLU MESELE CT
POW ERPHO NE
ON OFF
1 4
3
2
5
6
1
2
4
3
5
6
7
8
9
11 12 13
Note: Before connecting “ BYPASS” audio-in, turn the audio source volume to minimum to avoid
damage to the speakers.
1. Signal input indicator
2. Input selector
3. Volume control
4. IR window
5. Headphone output
6. Power switch
1. Power input socket with fuse
2. Right channel speaker terminal
3. Left channel terminalspeaker
4. BYPASS input
5. TAPE output
6. TAPE input
7. AUX input
8. TUNER input
9. XLR input
10. CD input
11. Bluetooth antenna
12. USB DAC input
13. Optical input
Parts Name
10
