Onkyo CR-555

34
Specifications
Amplifier Section
Tuner Section
CD
General
■ Audio Inputs
■ Audio Outputs
■ Others
Specifications and features are subject to change
without notice.
Rated Output Power
All channels: (European)
2 ch × 22 W at 4 ohms, 1 kHz, 2 ch driven
of 0.4% (IEC)
Damping Factor 22 (Front, 1 kHz, 8 Ω)
THD+N (Total Harmonic Distortion+Noise)
0.4% (1 kHz, 1 W)
Input Sensitivity and Impedance (Unbalance)
150 mV/47 kΩ (LINE)
Rated RCA Output Level and Impedance
0.15 V/330 Ω (LINE OUT)
Frequency Response 10 Hz - 100 kHz/±3 dB (LINE1)
Tone Control Characteristics
±6 dB, 80 Hz (BASS)
±8 dB, 10 kHz (TREBLE)
+8 dB, 30 Hz (PM.Bass)
Signal to Noise Ratio 100 dB (LINE, IHF-A)
Speaker Impedance 4 Ω - 16 Ω
FM Tuning Frequency Range
(European)
87.5 MHz - 108.0 MHz, RDS
(Others) 87.5 MHz - 108.0 MHz
AM Tuning Frequency Range (CR-555)
522 kHz - 1611 kHz
Preset Channel 40
Signal Readout Optical non-contact
Frequency Response 10 Hz - 20 kHz
Audio Dynamic Range 96 dB
THD (Total Harmonic Distortion)
0.025%
Wow and Flutter Below threshold of measurability
Audio Output/Impedance (Analog)
2.0 V (rms)/330 Ω
Power Supply AC 220 - 230 V, 50/60 Hz
Power Consumption (CR-555) 72 W
(CR-555DAB) 77 W
No-sound Power Consumption
(CR-555) 30 (USB 1ALoad) W
(CR-555DAB) 35 (USB 1ALoad:DAB)
W
Stand-by Power Consumption
(CR-555) 0.26 W
(CR-555DAB) 0.27 W
Dimensions (W × H × D)
215 mm × 119 mm × 331 mm
Weight 4.8 kg
Digital Optical: 1
Coaxial: 1
Analog LINE1, LINE2, AUX
Analog LINE OUT
Subwoofer Pre Output
1
Speaker Outputs Main (L, R)
Phones 1 (3.5 ø)
RI 1
USB 1
