Onkyo DX-C390 Service Manual

PRINTED CIRCUIT BOARD PARTS LIST
U10 : MAIN CIRCUIT PC BOARD NADG-8053
!: Sefety parts
CIRCUIT NO. PART NAME PART NO. DESCRIPTION REMARK
DG8053
C101 CHIP ELECT C 356721019R2 CEWX6.3V-100M
DG8053
C102 C-CERA C 332121045R1 CK725B1C-104K1
DG8053
C103 C-CERA C 332103325R1 CK725B1H-332K1
DG8053
C104 CHIP ELECT C 356723319R2 CEWX6.3V-330M
DG8053
C105 C-CERA C 332161040R1 CK725F1E-104Z1
DG8053
C106 CHIP ELECT C 356741009R2 CEWX16V-10M
DG8053
C107 C-CERA C 332161040R1 CK725F1E-104Z1
DG8053
C108 CHIP ELECT C 356721019R2 CEWX6.3V-100M
DG8053
C109 C-CERA C 332161040R1 CK725F1E-104Z1
DG8053
C110 C-CERA C 332104735R1 CK725B1H-473K1
DG8053
C111 C-CERA C 332161040R1 CK725F1E-104Z1
DG8053
C112 C-CERA C 332161040R1 CK725F1E-104Z1
DG8053
C113 C-CERA C 342102214R1 CC725CH1H-221J1
DG8053
C114 C-CERA C 332121045R1 CK725B1C-104K1
DG8053
C115 C-CERA C 342104714R1 CC725CH1H-471J1
DG8053
C117 CHIP ELECT C 356784799R2 CEWX50V-0.47M
DG8053
C118 C-CERA C 332101035R1 CK725B1H-103K1
DG8053
C119 C-CERA C 342102214R1 CC725CH1H-221J1
DG8053
C120 C-CERA C 332101525R1 CK725B1H-152K1
DG8053
C121 C-CERA C 332104735R1 CK725B1H-473K1
DG8053
C122 C-CERA C 332161040R1 CK725F1E-104Z1
DG8053
C123 CHIP ELECT C 356723319R2 CEWX6.3V-330M
DG8053
C124 C-CERA C 332161040R1 CK725F1E-104Z1
DG8053
C125 C-CERA C 332161040R1 CK725F1E-104Z1
DG8053
C126 C-CERA C 332161040R1 CK725F1E-104Z1
DG8053
C129 CHIP ELECT C 356722219R2 CEWX6.3V-220M
DG8053
C130 C-CERA C 332161040R1 CK725F1E-104Z1
DG8053
C131 CHIP ELECT C 356723319R2 CEWX6.3V-330M
DG8053
C151 C-CERA C 342101504R1 CC725CH1H-150J1
DG8053
C152 C-CERA C 342101804R1 CC725CH1H-180J1
DG8053
C157 CHIP ELECT C 356724709R2 CEWX6.3V-47M
DG8053
C159 CHIP ELECT C 356722219R2 CEWX6.3V-220M
DG8053
C164 C-CERA C 332161040R1 CK725F1E-104Z1
DG8053
C170 C-CERA C 332161040R1 CK725F1E-104Z1
DG8053
C172 C-CERA C 332172240R1 CK725F1C-224Z1
DG8053
C201 C-CERA C 332103335R1 CK725B1H-333K1
DG8053
C202 C-CERA C 332103335R1 CK725B1H-333K1
DG8053
C203 C-CERA C 332101035R1 CK725B1H-103K1
DG8053
C204 C-CERA C 332101225R1 CK725B1H-122K1
DG8053
C205 C-CERA C 332101225R1 CK725B1H-122K1
DG8053
C206 C-CERA C 342106814R1 CC725CH1H-681J1
DG8053
C207 C-CERA C 342106814R1 CC725CH1H-681J1
DG8053
C210 CHIP ELECT C 356723319R2 CEWX6.3V-330M
DG8053
C501 C-CERA C 332161040R1 CK725F1E-104Z1
DG8053
C502 CHIP ELECT C 356722219R2 CEWX6.3V-220M
DG8053
C503 C-CERA C 332161040R1 CK725F1E-104Z1
DG8053
C504 C-CERA C 342103304R1 CC725CH1H-330J1
DG8053
C505 C-CERA C 332181050R1 CK725F1A-105Z1
DG8053
C506 C-CERA C 332161040R1 CK725F1E-104Z1
DG8053
C507 C-CERA C 332161040R1 CK725F1E-104Z1
DG8053
C508 C-CERA C 332161040R1 CK725F1E-104Z1
DG8053
C509 C-CERA C 332161040R1 CK725F1E-104Z1
DG8053
C510 C-CERA C 332161040R1 CK725F1E-104Z1
DG8053
C511 C-CERA C 332161040R1 CK725F1E-104Z1
DG8053
C512 C-CERA C 332104735R1 CK725B1H-473K1
DG8053
C513 CHIP ELECT C 356722219R2 CEWX6.3V-220M
DG8053
C514 C-CERA C 332161040R1 CK725F1E-104Z1
DG8053
C551 C-CERA C 332104735R1 CK725B1H-473K1
DG8053
C552 C-CERA C 332161040R1 CK725F1E-104Z1
DG8053
C701 C-CERA C 332161040R1 CK725F1E-104Z1
DG8053
C702 CHIP ELECT C 356741009R2 CEWX16V-10M
DG8053
C703 C-CERA C 332161040R1 CK725F1E-104Z1
DG8053
C704 C-CERA C 332161040R1 CK725F1E-104Z1
50 of 63
