Onkyo DX-C390 Service Manual

DG8053
C705 C-CERA C 332161040R1 CK725F1E-104Z1
DG8053
C707 C-CERA C 332161040R1 CK725F1E-104Z1
DG8053
C709 C-CERA C 332161040R1 CK725F1E-104Z1
DG8053
C710 CHIP ELECT C 356780229R2 CEWX50V-2.2M
DG8053
C711 C-CERA C 342103304R1 CC725CH1H-330J1
DG8053
C713 C-CERA C 332161040R1 CK725F1E-104Z1
DG8053
C714 C-CERA C 332161040R1 CK725F1E-104Z1
DG8053
C715 C-CERA C 332161040R1 CK725F1E-104Z1
DG8053
D101 C-DIODE 223269R2 1SS355
DG8053
D101 or C-DIODE 223234R2 1SS352
DG8053
D701 C-DIODE 223269R2 1SS355
DG8053
D701 or C-DIODE 223234R2 1SS352
DG8053
D703 C-DIODE 223269R2 1SS355
DG8053
D703 or C-DIODE 223234R2 1SS352
DG8053
D704 ZENER D 224550560R2 UDZS5.6B
DG8053
L101 CHOKE COIL 231237K100R2 NCH-1475
DG8053
L102 CHOKE COIL 230921R2 BLM21B222SPT
DG8053
L103 CHOKE COIL 230921R2 BLM21B222SPT
DG8053
L104 CHOKE COIL 230921R2 BLM21B222SPT
DG8053
L151 CHOKE COIL 230921R2 BLM21B222SPT
DG8053
L154 CHOKE COIL 230921R2 BLM21B222SPT
DG8053
L155 CHOKE COIL 230921R2 BLM21B222SPT
DG8053
L156 CHOKE COIL 230947R2 BLM21B221SB
DG8053
L157 MPX COIL 232136 NSRF-2046
DG8053
L158 CHOKE COIL 230921R2 BLM21B222SPT
DG8053
L202 CHOKE COIL 230921R2 BLM21B222SPT
DG8053
L501 CHOKE COIL 230921R2 BLM21B222SPT
DG8053
L502 CHOKE COIL 230921R2 BLM21B222SPT
DG8053
L503 CHOKE COIL 230921R2 BLM21B222SPT
DG8053
P101A SOCKET 25052483 NSCT-16P2380
DG8053
P102A PLUG 25055367 NPLG-3P350
DG8053
P103A PLUG 25055369 NPLG-5P352
DG8053
P201A PLUG 25055979R2 NPLG-6P932
DG8053
P701A SOCKET 25052354 NSCT-17P2251
DG8053
P701A or SOCKET 25052538 NSCT-17P2435
DG8053
P904A PLUG 25055996 NPLG-10P948
DG8053
Q101 TR 2214373R2 2SA1162-O
DG8053
Q102 IC 22241585R2 CXA2581N
DG8053
Q103 IC 22241588R3 CXD3068Q
DG8053
Q151 IC 22240935R2 TC7WU04FU
DG8053
Q152 IC 22241965R2 WM8726
DG8053
Q153 IC 22274000GR2TO TC74VHCT00AFT
DG8053
Q154 IC(REGULATOR) 22278005FR2 MPC29L05T
DG8053
Q155 IC 22274004HR2TO TC74VHCU04FT
DG8053
Q201 IC 22241696R2 BA5984FP
DG8053
Q501 IC 3132-0930-0 LC78683E
DG8053
Q502 IC 22241909R2 IC41LV16100-50T
DG8053
Q551 IC 3132-0910-0 AK4103VF
DG8053
Q701 IC 3132-0950-0 MPD784225GC-237-8BT
DG8053
Q702 TR 2216250R2 DTC114EKA
DG8053
Q702 or TR 2214470R2 RN1402
DG8053
Q702 or TR 2216210R2 KRC104S
DG8053
Q703 IC 22274008GR2TO TC74VHCT08AFT
DG8053
Q704 IC 22274032GR2TO TC74VHCT32AFT
DG8053
Q705 IC 22274032GR2TO TC74VHCT32AFT
DG8053
Q706 IC 3132-0920-0 BR93L56F-WE2
DG8053
Q709 TR 2216240R2 DTA124EKA
DG8053
Q709 or TR 2214540R2 RN2403
DG8053
Q709 or TR 2216230R2 KRA103S
DG8053
R101 C-CARBON R 435031034R1 RN72K1J-103JE
DG8053
R102 C-CARBON R 435031034R1 RN72K1J-103JE
DG8053
R103 C-CARBON R 435031014R1 RN72K1J-101JE
DG8053
R104 C-CARBON R 435034704R1 RN72K1J-470JE
DG8053
R105 C-CARBON R 435034704R1 RN72K1J-470JE
DG8053
R107 C-CARBON R 435031044R1 RN72K1J-104JE
DG8053
R108 C-CARBON R 435031034R1 RN72K1J-103JE
DG8053
R109 C-CARBON R 435031034R1 RN72K1J-103JE
51 of 63
