Onkyo DX-C390 Service Manual

DG8053
R710 C-CARBON R 435036814R1 RN72K1J-681JE
DG8053
R711 C-CARBON R 435034714R1 RN72K1J-471JE
DG8053
R712 C-CARBON R 435031024R1 RN72K1J-102JE
DG8053
R713 C-CARBON R 435031024R1 RN72K1J-102JE
DG8053
R714 C-CARBON R 435031224R1 RN72K1J-122JE
DG8053
R715 C-CARBON R 435034714R1 RN72K1J-471JE
DG8053
R716 C-CARBON R 435032234R1 RN72K1J-223JE
DG8053
R717 C-CARBON R 435030004R1 RN72K1J-000JE
DG8053
R718 C-CARBON R 435030004R1 RN72K1J-000JE
DG8053
R719 C-CARBON R 435030004R1 RN72K1J-000JE
DG8053
R721 C-CARBON R 435031034R1 RN72K1J-103JE
DG8053
R722 C-CARBON R 435030004R1 RN72K1J-000JE <MDD>
DG8053
R723 C-CARBON R 435031034R1 RN72K1J-103JE
DG8053
R724 C-CARBON R 435034744R1 RN72K1J-474JE
DG8053
R725 C-CARBON R 435030004R1 RN72K1J-000JE
DG8053
R726 C-CARBON R 435034714R1 RN72K1J-471JE
DG8053
R727 C-CARBON R 435034714R1 RN72K1J-471JE
DG8053
R728 C-CARBON R 435034714R1 RN72K1J-471JE
DG8053
R729 C-CARBON R 435034714R1 RN72K1J-471JE
DG8053
R730 C-CARBON R 435034714R1 RN72K1J-471JE
DG8053
R731 C-CARBON R 435034714R1 RN72K1J-471JE
DG8053
R732 C-CARBON R 435031224R1 RN72K1J-122JE
DG8053
R733 C-CARBON R 435034714R1 RN72K1J-471JE
DG8053
R734 C-CARBON R 435034714R1 RN72K1J-471JE
DG8053
R735 C-CARBON R 435034714R1 RN72K1J-471JE
DG8053
R736 C-CARBON R 435034714R1 RN72K1J-471JE
DG8053
R737 C-CARBON R 435034714R1 RN72K1J-471JE
DG8053
R738 C-CARBON R 435034714R1 RN72K1J-471JE
DG8053
R739 C-CARBON R 435034714R1 RN72K1J-471JE
DG8053
R740 C-CARBON R 435034714R1 RN72K1J-471JE
DG8053
R741 C-CARBON R 435034714R1 RN72K1J-471JE
DG8053
R742 C-CARBON R 435034714R1 RN72K1J-471JE
DG8053
R743 C-CARBON R 435031224R1 RN72K1J-122JE
DG8053
R744 C-CARBON R 435031224R1 RN72K1J-122JE
DG8053
R745 C-CARBON R 435030004R1 RN72K1J-000JE
DG8053
R746 C-CARBON R 435031034R1 RN72K1J-103JE
DG8053
R747 C-CARBON R 435031024R1 RN72K1J-102JE
DG8053
R748 C-CARBON R 435033314R1 RN72K1J-331JE
DG8053
R749 C-CARBON R 435034734R1 RN72K1J-473JE
DG8053
R750 C-CARBON R 435034734R1 RN72K1J-473JE
DG8053
R751 C-CARBON R 435034734R1 RN72K1J-473JE
DG8053
R752 C-CARBON R 435032224R1 RN72K1J-222JE
DG8053
R753 C-CARBON R 435031224R1 RN72K1J-122JE
DG8053
R754 C-CARBON R 435030004R1 RN72K1J-000JE
DG8053
R755 C-CARBON R 435030004R1 RN72K1J-000JE
DG8053
R756 C-CARBON R 435030004R1 RN72K1J-000JE
DG8053
R757 C-CARBON R 435030004R1 RN72K1J-000JE
DG8053
R758 C-CARBON R 435030004R1 RN72K1J-000JE
DG8053
R759 C-CARBON R 435030004R1 RN72K1J-000JE
DG8053
R760 C-CARBON R 435030004R1 RN72K1J-000JE
DG8053
R762 C-CARBON R 435030004R1 RN72K1J-000JE
DG8053
R763 C-CARBON R 435030004R1 RN72K1J-000JE
DG8053
R764 C-CARBON R 435031034R1 RN72K1J-103JE
DG8053
R765 C-CARBON R 435030004R1 RN72K1J-000JE
DG8053
R766 C-CARBON R 435034734R1 RN72K1J-473JE
DG8053
R767 C-CARBON R 435034734R1 RN72K1J-473JE
DG8053
R768 C-CARBON R 435034734R1 RN72K1J-473JE
DG8053
R769 C-CARBON R 435033324R1 RN72K1J-332JE
DG8053
X151 CRYSTAL 2300-2340-0 HC-49/U03C16.9344MHz
DG8053
X701 CERA LOCK 3010361R2 CSTCE12M5G52-R0
U20 : DISPLAY CIRCUIT PC BOARD NADIS-8054
CIRCUIT NO. PART NAME PART NO. DESCRIPTION REMARK
DIS-8054
C801 ELECT C 394821017 CE04W6.3V100M(SSK)
DIS-8054
C802 C-CERA C 332161040R1 CK725F1E-104Z1
DIS-8054
C804 ELECT C 394841007 CE04W16V10M(SSK)
DIS-8054
C806 C-CERA C 332161040R1 CK725F1E-104Z1
54 of 63
