Onkyo DX-C390 Service Manual

DIS-8054
C807 C-CERA C 332152230R1 CK725F1H-223Z1
DIS-8054
C808 ELECT C 394880227 CE04W50V2.2M(SSK)
DIS-8054
C809 C-CERA C 332161040R1 CK725F1E-104Z1
DIS-8054
C810 C-CERA C 332152230R1 CK725F1H-223Z1
DIS-8054
C811 C-CERA C 332152230R1 CK725F1H-223Z1
DIS-8054
C812 C-CERA C 342103304R1 CC725CH1H-330J1
DIS-8054
C813 C-CERA C 342103304R1 CC725CH1H-330J1
DIS-8054
C814 C-CERA C 342101014R1 CC725CH1H-101J1
DIS-8054
C815 C-CERA C 342101014R1 CC725CH1H-101J1
DIS-8054
C816 C-CERA C 342101014R1 CC725CH1H-101J1
DIS-8054
D804 ZENER D 224551100R2 UDZS11B
DIS-8054
P801A SOCKET AS 7012-6664-0 NSAS-6P1231
DIS-8054
Q801 IC 22241989R3 MPD780232GC-091-8BT
DIS-8054
Q802 FL TUBE 2460-2070-0 HNV-12SM57
DIS-8054
Q802A HOLDER 4154-7161-0 (FL)
DIS-8054
Q803 TR 2214394R2 2SC2859-Y
DIS-8054
Q804 TR 2214394R2 2SC2859-Y
DIS-8054
Q805 TR 2214530R2 RN2402
DIS-8054
Q806 TR 2214530R2 RN2402
DIS-8054
Q807 TR 2214530R2 RN2402
DIS-8054
Q808 TR 2216470R2 DTC114YKA
DIS-8054
Q808 or TR 2216260R2 RN1407
DIS-8054
Q808 or TR 2216340R2 KRC107S
DIS-8054
Q809 TR 2216470R2 DTC114YKA
DIS-8054
Q809 or TR 2216260R2 RN1407
DIS-8054
Q809 or TR 2216340R2 KRC107S
DIS-8054
Q810 REMO SENS 241351 SPS-440-1-VP
DIS-8054
Q811 TR 2216470R2 DTC114YKA
DIS-8054
Q811 or TR 2216260R2 RN1407
DIS-8054
Q811 or TR 2216340R2 KRC107S
DIS-8054
R801 C-CARBON R 435031034R1 RN72K1J-103JE
DIS-8054
R802 C-CARBON R 435033314R1 RN72K1J-331JE
DIS-8054
R803 C-CARBON R 435033314R1 RN72K1J-331JE
DIS-8054
R804 C-CARBON R 435034714R1 RN72K1J-471JE
DIS-8054
R805 C-CARBON R 435036814R1 RN72K1J-681JE <MDD>
DIS-8054
R805 C-CARBON R 435036814R1 RN72K1J-681JE <MPA,MPP>
DIS-8054
R806 C-CARBON R 435035604R1 RN72K1J-560JE
DIS-8054
R807 C-CARBON R 435032724R1 RN72K1J-272JE
DIS-8054
R808 C-CARBON R 435033914R1 RN72K1J-391JE
DIS-8054
R809 C-CARBON R 435034714R1 RN72K1J-471JE
DIS-8054
R810 C-CARBON R 435038214R1 RN72K1J-821JE
DIS-8054
R811 C-CARBON R 435031024R1 RN72K1J-102JE
DIS-8054
R812 C-CARBON R 435031824R1 RN72K1J-182JE
DIS-8054
R813 C-CARBON R 435033914R1 RN72K1J-391JE
DIS-8054
R814 C-CARBON R 435034714R1 RN72K1J-471JE
DIS-8054
R815 C-CARBON R 435038214R1 RN72K1J-821JE
DIS-8054
R816 C-CARBON R 435031024R1 RN72K1J-102JE
DIS-8054
R817 C-CARBON R 435031824R1 RN72K1J-182JE
DIS-8054
R818 C-CARBON R 435033924R1 RN72K1J-392JE
DIS-8054
R819 C-CARBON R 435033924R1 RN72K1J-392JE
DIS-8054
R826 C-CARBON R 435032724R1 RN72K1J-272JE
DIS-8054
R827 C-CARBON R 435032724R1 RN72K1J-272JE
DIS-8054
R828 C-CARBON R 435032724R1 RN72K1J-272JE
DIS-8054
R829 C-CARBON R 435034714R1 RN72K1J-471JE
DIS-8054
R830 C-CARBON R 435034714R1 RN72K1J-471JE
DIS-8054
R831 C-CARBON R 435032234R1 RN72K1J-223JE
DIS-8054
R832 C-CARBON R 435032234R1 RN72K1J-223JE
DIS-8054
R834 C-CARBON R 435031014R1 RN72K1J-101JE
DIS-8054
R835 C-CARBON R 435031014R1 RN72K1J-101JE
DIS-8054
R836 C-CARBON R 435031044R1 RN72K1J-104JE
DIS-8054
R837 C-CARBON R 435030004R1 RN72K1J-000JE
DIS-8054
R888 C-CARBON R 435031044R1 RN72K1J-104JE
DIS-8054
R889 C-CARBON R 435031044R1 RN72K1J-104JE
DIS-8054
R890 C-CARBON R 435031044R1 RN72K1J-104JE
DIS-8054
R891 C-CARBON R 435031044R1 RN72K1J-104JE
DIS-8054
R892 C-CARBON R 435031044R1 RN72K1J-104JE
DIS-8054
R893 C-CARBON R 435031044R1 RN72K1J-104JE
