HT-S3400
5.1-CHANNEL HOME THEATER RECEIVER/SPEAKER PACKAGE
H
DMI
®
S
upport for 3D Video and Audio
R
eturn Channel
T
he four HDMI inputs on the HT-S3400’s A/V receiver let
you simultaneously connect high-def sources such as a
B
lu-ray player, a game console, and a cable/satellite tuner.
A
single output then sends a pristine signal to your
connected high-resolution display. The HDMI
i
mplementation on this receiver supports both 3D video
and an Audio Return Channel. 3D video brings exciting
possibilities to home enter tainment, with movie, game, and
b
roadcast content on the increase and 3D-compatible TVs
coming to market. Meanwhile, the Audio Return Channel
a
llows audio content received directly by your HDTV’s
tuner to be sent “upstream” via HDMI to your A/V receiver,
without the need for a separate S/PDIF audio cable.
Decoding of High-Definition Surround-Sound
C
odecs
T
he HT-S3400’s A/V receiver can decode Dolby
®
T
rueHD
and DTS-HD Master Audio
™
—two lossless formats that
enable delivery of a bit-for-bit soundtrack identical to the
s
tudio master track. These codecs take advantage of the
high data capacity of the Blu-ray Disc format.
C
onvenient Overlaid On-Screen Display via HDMI
C
hanging your A/V receiver’s settings is now more seamless
than ever, thanks to Onkyo’s overlaid On-Screen Display
(OSD) feature. On-screen set-up menus appear overlaid on
t
he video image you’re watching. This means you can adjust
the settings immediately, without having to switch back and
f
orth from a blank screen background.
1
92 kHz/24-Bit TI Burr-Brown DACs Improve
Jitter Performance to Deliver Clearer Sound
High-quality Burr-Brown DACs work to optimize analog
audio performance on the HT-S3400’s A/V receiver. These
D
ACs perform advanced 24-bit signal processing and
support sampling rates of up to 192 kHz, while displaying
high resistance to clock jitter.
Audyssey Technologies to Optimize the Listening
Experience
The HT-S3400 comes with two sound-enhancing Audyssey
technologies.
(1) Audyssey Dynamic EQ
®
maintains a consistent bass response,
tonal balance, and surround-sound effect at different volume levels,
s
o you can enjoy the natural dynamics of your content regardless of
the volume.
(2) Audyssey Dynamic Volume
®
automatically compensates for
volume fluctuations in different audio content—for example, during
commercial breaks—while optimizing the dynamic range.
Universal Port for Single-Cable Connection of
Optional Onkyo Dock for iPod/iPhone
A proprietary Universal Port located on the rear side of
the HT-S3400’s A/V receiver lets you connect an optional
UP-A1 Dock for iPod/iPhone. A key advantage of the
Universal Port is that it accepts video and audio signals
through the same cable that sends a power supply from
the receiver to the devices. Net result: more connectivity,
less cable clutter.
General
Power Supply AC 220–240 V~, 50/60 Hz
Power Consumption 370 W
Dimensions (W x H x D) 435 x 150 x 328 mm
Weight 7.7/7.6 kg
SPEAKER SYSTEM
Speaker Type
Front Full-range, Bass reflex
C
enter Full-range, Acoustic suspension
Surround Full-range, Bass reflex
Subwoofer Bass reflex
D
rivers
Front 8 cm cone
C
enter 8 cm cone x 2
S
urround 8 cm cone
Subwoofer 20 cm cone
F
requency Response
Front 80 Hz–20 kHz
Center 80 Hz–20 kHz
S
urround 80 Hz–20 kHz
Subwoofer 30 Hz–150 Hz
Output Sound Pressure Level
Front 82 dB/W/m
C
enter 84 dB/W/m
Surround 80 dB/W/m
Subwoofer 83 dB/W/m
Max. Input Power
F
ront/Center/Surround 120 W
Subwoofer 130 W
Nominal Impedance Front/Center/Surround/Subwoofer
6
Ω
G
eneral
Dimensions (W x H x D)
F
ront 101 x 231 x 119 mm
Center 230 x 103 x 115 mm
S
urround 101 x 161 x 115 mm
Subwoofer 295 x 345 x 368 mm
Weight
F
ront 0.9 kg
Center 1.3 kg
Surround 0.7 kg
S
ubwoofer 6.4 kg
C
ARTON
D
imensions (W x H x D) 537 x 751 x 414 mm
Weight 22.5 kg
Supplied Accessories
•
Indoor FM antenna • AM loop antenna • Color-coded speaker cable
• Subwoofer cable • Instruction manual • Quick set-up guide
• Remote controller • AA (R6) batteries* x 2
*Not included with Chinese model.
Due to a policy of continuous product improvement, Onkyo reserves the right to change specifications and appearance without notice. Manufactured under license from Dolby Laboratories. Dolby, Pro Logic, and the double-D symbol are trademarks of Dolby Laboratories. DTS,
DTS-HD, and the Symbol are registered trademarks and the DTS logos are trademarks of DTS, Inc. Manufactured under license from Audyssey Laboratories, Inc. U.S. and foreign patents pending. Audyssey Dynamic EQ and Audyssey Dynamic Volume are registered trademarks of
Audyssey Laboratories, Inc. HDMI, the HDMI logo, and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries. iPod and iPhone are trademarks of Apple Inc., registered in the U.S. and other
countries. x.v.Color is a trademark of Sony Corporation. Music Optimizer, CinemaFILTER, and Theater-Dimensional are trademarks of Onkyo Corporation. All other trademarks and registered trademarks are the property of their respective holders.
NPR No. 11N07 01/11
SPECIFICATIONS
A
/V RECEIVER
Amplifier Section
P
ower Output
Front L/R 120 W/Ch
(6 Ω, 1 kHz, 1%, 1 channel driven, JEITA)
C
enter 120 W
(6 Ω, 1 kHz, 1%, 1 channel driven, JEITA)
S
urround L/R 120 W/Ch
(6 Ω, 1 kHz, 1%, 1 channel driven, JEITA)
Subwoofer 120 W/Ch
(
6 Ω, 1 kHz, 1%, 1 channel driven, JEITA)
Dynamic Power 160 W (3 Ω, Front)
1
25 W (4 Ω, Front)
85 W (8 Ω, Front)
THD+N (Total Harmonic Distortion + Noise)
0
.08% (20 Hz–20 kHz, half power)
Damping Factor 60 (Front, 1 kHz, 8 Ω)
Input Sensitivity and Impedance
2
00 mV/47 kΩ (Line)
Rated RCA Output Level and Impedance
200 mV/2.2 kΩ (Rec out)
Maximum RCA Output Level and Impedance
2.0 V/2.2 kΩ (Rec out)
Frequency Response 20 Hz–50 kHz/+1 dB, -3 dB (DSP bypass)
T
one Control ±10 dB, 50 Hz (Bass)
±10 dB, 20 kHz (Treble)
Signal-to-Noise Ratio 100 dB (Line, IHF-A)
Speaker Impedance 6 Ω–16 Ω
Video Section
Input Sensitivity/Output Level and Impedance
Video 1.0 Vp–p/75 Ω (Component Y)
0.7 Vp–p/75 Ω (Component P
B/CB, PR/CR)
1.0 Vp–p/75 Ω (Composite)
Component Video Frequency Response
5 Hz–100 MHz/0 dB, -3 dB
Tuner Section
Tuning Frequency Range
FM 87.5 MHz–108 MHz
AM 522 kHz–1,611 kHz
530 kHz–1,710 kHz
FM/AM Preset Memory 40 stations
Front View Rear view
