Onkyo HT-R570 Service Manual

EXPLODED
Q6066 or TR 2SA1695-P ( 1) 2202516
EXPLODED
Q6066 or TR 2SA1941-R ( 1) 2203052
EXPLODED
Q6066 or TR MP130S-O ( 1) 2203673
EXPLODED
Q6066 or TR MP130S-Y ( 1) 2203674
EXPLODED
Q6066 or TR MP130S-P ( 1) 2203676
EXPLODED
Q6066 or TR KTA1962A-R ( 1) 2203942
EXPLODED
Q6066 or TR KTA1962A-O ( 1) 2203943
[TRANS COIL]
EXPLODED
T901 P TRANS NPT-1516D 1 2301798
[SW TRM]
EXPLODED
F6901 FUSE 10A-UL/T-233 1 252330GR
EXPLODED
F6901 or FUSE 10A-T/UL-ST2 ( 1) 252333GR
EXPLODED
F6902 FUSE 10A-UL/T-233 1 252330GR
EXPLODED
F6902 or FUSE 10A-T/UL-ST2 ( 1) 252333GR
EXPLODED
F901 FUSE 8A-UL/T-233 1 252329GR
EXPLODED
F901 or FUSE 8A-T/UL-ST2 ( 1) 252261GR
EXPLODED
P101 FFC NCFC7-111512 1 2047111512
EXPLODED
P701 FFC NCFC7-332012 1 2047332012
EXPLODED
P901 AC CORD AS-UC-2 1 253368AYUN
EXPLODED
P901 or AC CORD AS-UC-2 ( 1) 253368BLTK
[CHASSIS SCREW]
EXPLODED
A001 CHASSIS TX-SR507 1 27100533B N
EXPLODED
A003 BOTTOM LEG --- 4 27175432C
EXPLODED
A005 CUSHION --- 4 28141664
EXPLODED
A007 SCREW 3TTB+8B(3CM)SR 4 801637
EXPLODED
A009 HOLDER KGLS-8RT 3 27190503A
EXPLODED
A010 HOLDER KGPS-8RF 1 27191044
EXPLODED
A011 HOLDER KGLS-10RT 1 27190428A
EXPLODED
A013 HOLDER KGPS-14RF 2 27190802
EXPLODED
A015 HOLDER KGPS-14RF 1 27190802
EXPLODED
A019 HOLDER KGPS-16RF 1 27190991
EXPLODED
A021 HOLDER KGLS-22S 2 27190369
EXPLODED
A023 HOLDER KGLS-22S 1 27190369
EXPLODED
A025 SCREW 4TTC+8C(3BC) 4 830440089GR
EXPLODED
A030 HEAT SINK 507 1 27160633
EXPLODED
A032 RETAINER (HL) 1 27142138A
EXPLODED
A034 RETAINER (HR) 1 27142139A
EXPLODED
A036 SCREW 3TTB+8B(3CM)SR 4 801637
EXPLODED
A038 SCREW 3TTB+8B(3CM)SR 2 801637

Onkyo HT-R570 Specifications

General

Brand	Onkyo
Model	HT-R570
Category	Receiver
Language	English
