Onkyo HT-R570

EXPLODED
A262 TAPE TAPE(CLOTH-16U) 1 29110083
EXPLODED
A264 CUSHION --- 3 28141681
EXPLODED
A330 KNOB (VOL) BLACK 1 28326514 <B>
EXPLODED
A330 KNOB (VOL)N(S) 1 28326669 <S>
EXPLODED
A340 COVER (B) (Bent) 1 28210031 <B>
EXPLODED
A340 COVER (S) (Bent) 1 28210032 <S>
EXPLODED
A340 COVER (B) (Not Bent) 1 28210031Z <B>
EXPLODED
A340 COVER (S) (Not Bent) 1 28210032Z <S>
EXPLODED
A342 SCREW 3TTB+8B(3BC) 7 838430088GR <B>
EXPLODED
A344 SCREW 3TTB+8B(3CM)SR 7 801637 <S>
EXPLODED
A350 PLATE (COVER) 1 27262834A <BDC, BDD>
EXPLODED
A350 PLATE (COVER) 1 27262835A <SDC>
EXPLODED
A354 HOLDER (PLATE) 8 27191337 <BDC, BDD>
EXPLODED
A354 HOLDER (PLATE) 8 27191333A <SDC>
EXPLODED
A360 LABEL (COVER) 1 29390767
EXPLODED
A362 LABEL HOOKUP-ONKYO 1 29363194
HT-R570
PC BOARD PARTS LIS
T
U001 AMPLIFIER PC BOARD (BAAF-0008-1E)
U0011 TRANS.SEL.TERMINAL PC BOARD (BAPS-0009-1E)
U0012 TRANS.SEL.TERMINAL PC BOARD (BAPS-0010-1E)
U0013 THERMAL SENSOR PC BOARD (BAETC-0011E)
U00014 ETC PC BOARD (BAETC-0012-1E)
CIRCUIT. NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[SEMI CONDUCTOR]
PCB-1
D5000 ZENER D MTZJ5.6B 1 224470562T
PCB-1
D5001 ZENER D MTZJ5.6B 1 224470562T
PCB-1
D5002 ZENER D MTZJ5.6B 1 224470562T
PCB-1
D5003 ZENER D MTZJ5.6B 1 224470562T <1E>
PCB-1
D5004 ZENER D MTZJ5.6B 1 224470562T <1E>
PCB-1
D5005 ZENER D MTZJ5.6B 1 224470562T
PCB-1
D5006 ZENER D MTZJ5.6B 1 224470562T
PCB-1
D5671 ZENER D MTZJ6.2B 1 224470622T
