Onkyo HT-R980 (B) - Page 67

U003
DG-AS(MPU/DIR/DAC Asy)
U0030+U0032
BADG-0364-1U * 1 1B247564-1U N <B CMPP>
U0030
DG-AS
(
MPU/DIR/DAC As
y)
BADG-0364-1T 1 1B2475364-1T N <B CMDC>
U0030
DG-AS
(
MPU/DIR/DAC As
y)
BADG-0364-1U 1 1B2475364-1U N <B CMPP>
U0031
PWB
(
U Port Jack
)
BAETC-0365-1
T
1 1B2475365-1T N <B CMDC>
U0031
PWB
(
U Port Jack
)
BAETC-0365-1U 1 1B2475365-1U N <B CMPP>
CIRCUIT PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[SEMI CONDUCTOR]
D110 C-DIODE KDS4148U 1 223283R2 NSP
D110 or C-DIODE 1SS352 ( 1) 223234R2 NSP
D110 or C-DIODE MA2J111 ( 1) 223279R2 NSP
D111 C-DIODE KDS4148U 1 223283R2 NSP
D111 or C-DIODE 1SS352 ( 1) 223234R2 NSP
D111 or C-DIODE MA2J111 ( 1) 223279R2 NSP
D112 ZENER D UDZS10B 1 224551000R2 <B CMDC, B CMPP>
D131 C-DIODE KDS4148U 1 223283R2 NSP
D131 or C-DIODE 1SS352 ( 1) 223234R2 NSP
D131 or C-DIODE MA2J111 ( 1) 223279R2 NSP
D132 C-DIODE KDS4148U 1 223283R2 NSP
D132 or C-DIODE 1SS352 ( 1) 223234R2 NSP
D132 or C-DIODE MA2J111 ( 1) 223279R2 NSP
D182 DIODE RL1N4003 1 22380260T
D183 DIODE RL1N4003 1 22380260T
D601 C-DIODE KDS4148U 1 223283R2 NSP
D601 or C-DIODE 1SS352 ( 1) 223234R2 NSP
D601 or C-DIODE MA2J111 ( 1) 223279R2 NSP
D701 C-DIODE KDS4148U 1 223283R2 NSP
D701 or C-DIODE 1SS352 ( 1) 223234R2 NSP
D701 or C-DIODE MA2J111 ( 1) 223279R2 NSP
D702 C-DIODE KDS4148U 1 223283R2 NSP
D702 or C-DIODE 1SS352 ( 1) 223234R2 NSP
D702 or C-DIODE MA2J111 ( 1) 223279R2 NSP
Q101 IC LC72725KV-TLM-E 1 22242584R2 <B CMPP>
Q111 TR 2SC2235-Y(TPE6_F) 1 2211654T <B CMDC, B CMPP>
Q131 IC TC74HCU04AF 1 222740046R2TO
Q131 or IC 74HCU04F ( 1) 222740046R2
Q153 IC R1EX25064ASA00A 1 22242581R2
Q153 or IC M95640-WMN6TP ( 1) 22242643R2 N
Q181 TR KRC105S 1 2217290R2
Q181 or TR RN1405 ( 1) 2214500R2
Q2804 IC NJM4580M-D 1 22241448R2
Q301 IC PCM9210PTR 1 22242629R2 N
Q302 IC PCM1690DCAR 1 22242599R2
Q401 IC NJM4580M-D 1 22241448R2
