Onkyo HTX-22HDX Service Manual

1/50 PAGE
HTX-22HDX
<Note>
Parts marked by "NSP" are generally unavailable because
they are not in our Master Spare Parts List.
<Notes>
<MPP> : European model only
<MDC> : Canadian model only
EXPLODED VIEW PARTS LIST
AMPLIFIER SECTION
REF. NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
EXPLODED
[CHASSIS SCREW]
EXPLODED
A001 CLEAR PLT MDC/MPP 1 28192295
N
EXPLODED
A002 F BRACKET --- 1 27111573A
N
<MPP>
EXPLODED
A002 F BRACKET MDC 1 27111588
N
<MDC>
EXPLODED
A003 KNOB (TOP) 1 28326815A
N
EXPLODED
A008 SCREW 3TTB+8B(3BC) 6 838430088GR
EXPLODED
A009 SCREW 3TTB+8B(3BC) 4 838430088GR
EXPLODED
A010 SCREW 3TTB+8B(3BC) 4 838430088GR
EXPLODED
A012 CHASSIS --- 1 27100520B
N
EXPLODED
A014 TAPE TAPE(CLOTH-8U) 1 29110082
EXPLODED
A016 CUSHION 20x20xt0.5 1 28141465GR
EXPLODED
A018 SHLD PLT (F) 1 27150529A
N
EXPLODED
A019 RIVET P-RIVET NRP-345 2 880009
EXPLODED
A020 SCREW 4TTC+8C(3BC) 4 830440089GR
EXPLODED
A021 HEAT SINK --- 1 27160644
EXPLODED
A022 TAPE TAPE(CLOTH-8U) 1 29110082
EXPLODED
A023 SCREW 3SMS8W.SW+14B(CU) 6 801634
EXPLODED
A024 SCREW 3TTB+8B(3BC) 6 838430088GR
EXPLODED
A025 SCREW 3TTB+8B(3BC) 1 838430088GR
EXPLODED
A028 SCREW 3TTB+8B(3BC) 2 838430088GR
EXPLODED
A032 COVER --- 1 28210053A
N
EXPLODED
A033 SCREW 3TTB+8B(3BC) 3 838430088GR
EXPLODED
A034 CUSHION --- 2 28141765
NOTE : THE COMPONENTS IDENTIFIED BY THE MARK
! ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH PART
NUMBER SPECIFIED.
