Onkyo HTX-22HDX Service Manual

4/50 PAGE
EXPLODED
REF. NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
EXPLODED
SP01a COMPLETE UNIT ALL (With AMP UNIT / With SPEAKER UNIT) 1
000-HTX22HDXBMPPCSER
N
<MPP>
EXPLODED
SP01b COMPLETE UNIT ALL (With AMP UNIT / With SPEAKER UNIT) 1
000-HTX22HDXBMDCCSER
N
<MDC>
EXPLODED
SP02a COMPLETED ASS'Y Without AMP UNIT (With SPEAKER UNIT) 1
000-HTX22HDXBMPPESER
N
<MPP>
EXPLODED
SP02b CABINET ASS'Y Without AMP UNIT (With SPEAKER UNIT) 1
000-HTX22HDXBMDCESER
N
<MDC>
EXPLODED
SP03 WOOFER UNIT WF / 16cm 3ohm 1 300-DX22HDX1600
EXPLODED
SP04 FOOT --- 4 D243-TX2201B-00
EXPLODED
SP05 SCREW BIND HEAD 4 x 25mm (SP UNIT/FOOT) 12 411-BE4025AB1
EXPLODED
SP06 SCREW BIND HEAD 4 x 20mm (AMP) 5 411-BE4020AB1
EXPLODED
SP12 NETWORK ASS'Y UNIT-AMP L=500 1 310-X22HDX-11
EXPLODED
SP15a SPEC LABEL MPP 1 600-HDXMPP-00
N
EXPLODED
SP15b SPEC LABEL MDC 1 600-HDXMDC-00
N
EXPLODED
SP16 UL LABEL --- 1 660-HTS770-00 <MDC>
EXPLODED
SP20a SPEAKER ASS'Y HTX-22HDX ST (B)MP 1 ANM1SX22H-BM70
N
<MPP>
EXPLODED
SP20b SPEAKER ASS'Y HTX-22HDX ST (B)MC 1 ANM1SX22H-BM10
N
<MDC>
HTX-22HDX
PRINTED CIRCUIT BOARD PARTS LIS
T
PWB1
U01 HDMI PC board (BAHDM-0324-1A *)
PWB1
CIRCUIT NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
PWB1
[SEMI CONDUCTOR]
PWB1
D8100 DIODE XBS303V17R 1 22380365R2
