PANEL VIEW
Subwoofer SWA-155X (front panel)
Subwoofer SWA-155X (rear panel)
SWA
-
155X
POWER
POWERED SUBWOOFER
POWER indicator
Lights up green when the
power is turned on.
POWERED SUBWOOFER SYSTEM
SWA-155X
L
C
R
L
R
SUBWOOFER
CONTROL
FRONT
SURROUND
SUBWOOFER
R
L
CENTER
FRONT
SPEAKERS
SURROUND
SPEAKERS
MULTI CH INPUT
SUBWOOFER CONTROL
jack
Connect this jack to the
PDR-155 SUBWOOFER
CONTROL jack.
MULTI CH INPUT jacks
Connect these jacks to the
PDR-155 MULTI CH OUT-
PUT jacks.
Power cable
SURROUND SPEAKERS connectors
Connect the D-M3 left/right surround speakers here.
FRONT SPEAKERS
connectors
Connect the D-M7 front
L/R speakers to the L/R
connectors and the D-M3
center speaker to the C
connector.
Cooling fan
This fan starts rotating
when the output exceeds
a certain threshold to
release the heat inside
the subwoofer.
