HA12167FB/HA12169FB
6
Pin Description (V
CC
= 14 V, Ta = 25°C, No signal, The value in the show typical
value.) (Cont)
Pin No.
(QFP-80)
Terminal
Name Zin DC Voltage Equivalent Circuit Description
68 CONT 3.3 k V
CC
/2 – 1.5 V
to V
CC
/2
DAC
OUT
V /2
CC
DAC output
volume control
input
73
13 EQ CONT 1.65 k
48
10 LM DET — 0.2 V
LM
OUT
GND
LM DET
Time constant pin
for level meter
51
11 LM OUT — 0.2 V Level meter output
50
45 NR ON/OFF 100 k —
GND
Mode control time
constant
44 C/B
43 MPX
