AM
Antenna
An
AM
loop
antenna
is
included
in
the
installation
in-
structions
bag.
Insert
it
into
the
holder
on
the
rear
panel.
Swing
one
end
of
the
antenna
away
from
the
rear
panel
to
the
position
that
gives
the
best
reception.
If
reception
is
stdl
unsatisfactory,
completely
remove
the
loop
antenna
from
the
rear
panel
and
hang
!tt
on
a
wall
or
other
surface
in
the
position
that
gives
the
best
reception.
Be
sure
the
antenna
is
not
near
speakers,
power
cords,
television
sets,
VCRs,
and
motorized
appliances.
When
using
an
outdoor
AM
antenna,
do
not
remove
the
loop
antenna.
Connect
both
antennas
to
the
AM
antenna
terminals.
NOTE:
|
AM
reception
its
easily
affected
by
television
sets
and
VCRs.
Therefore,
AM
reception
may
be
poor
:f
this
unit
is
placed
too
closed
to
a
TV
or
VCR.
Speaker
Connections
When
connecting
speakers,
proper
polarity
is
important.
Always
connect
the
(+)
terminal
(red)
on
the
amplifier
to
the
(+)
terminal
on
the
speaker
and
the
(—)
terminal
(black)
on
the
amplifier
to
the
(—)
terminal
on
the
speaker.
@
Speaker
load
impedance
Is
very
important.
Only
speaker
systems
rated
at
8
ohms
or
more
should
be
used
with
this
unit.
If
only
one
pair
of
speakers
is
used,
the
load
impedance
must
be
at
least
4
ohms.
@
Do
not
connect
a
single
speaker
in
parallel
to
the
right
and
left
channe!
outputs.
@
Use
speaker
cables
that
have
a
low
impedance
and
that
are
as
short
as
possible.
#
Aitach
speaker
cables
to
the
rear
panel
Speaker
terminals
with
care,
being
sure
that
connections
are
made
firmly
and
that
there
is
no
possibility
of
a
short
circuit
occurring.
Turntable
Connections
Connect
the
output
leads
of
the
turntable
to
the
PHONO
jacks.
Be
sure
to
connect
the
ground
(earth)
lead
wire
from
the
turntable
to
the
ground
terminal
(GND).
Lack
of
proper
ground
connection
will
cause
hum.
Turntables
not
pro-
vided
with
GND
wires
do
not
need
to
be
connected.
1.
Place
the
turntable
on
a
firm
shelf
or
deck
free
from
vibrations
(especially
those
generated
by
the
speaker
system).
If
the
turntable
is
permitted
to
pick
up
such
unwanted
vibrations,
not
only
will
the
performance
of
the
unit
drop,
but
distortion
in
the
bass
frequencies
and
howling
tn
the
speakers
may
also
occur.
2.
Check
the
turntable
instruction
manual
for
any
ather
precautions.
3.
The
loud
noises
that
occur
when
connecting
and
dis-
connecting
the
turntable
leads,
replacing
the
cartridge
or
lowering
the
tonearm
could
damage
the
speakers.
Always
turn
the
power
switch
off
before
making
con-
nections.
4.
lf
a
compatible
Onkyo
remote
contro}
turntable
is
used
with
this
unit,
the
TX-84
remote
controller
can
also
be
used
to
start
and
stop
turntable
operation.
In
this
case,
connect
the
supplied
phono
DIN
cord
plug
to
the
DIN
type
remote
control
jack
on
the
turntable
and
the
turntable
remote
control
jack
on
the
rear
panel
of
TX-84.
5.
The
turntable
can
be
remotely
controlled
only
with
the
TX-84.
Compatible
Onkyo
Remote
Control
Turntables
CP-1057F
CP-1044F
CP-1055F
USA
model
(AC120V)
only
CP-1055F
II
CP-1046F
Compact
Disc
Player
or
Other
Component
Connect
the
output
leads
of
the
CD
player
or
an
additional
audio
component
to
the
CD
jacks.
An
Onkyo
CD
player
with
remote
control
can
be
operated
by
the
TX-84/82's
remote
control
transmitter.
For
more
details,
refer
to
your
CD
player
instruction
manual.
Onkyo
CD
players
that
can
be
operated
by
the
remote
control
transmitter:
DX-200
DX-330
*
DX-130
DX-320 DX-230
DX-220
«
Connect
the
2.5mm
plug
cord
(that
is
provided
for
re-
mote
control
operation
of
the
DX-130)
to
the
CD
remote
cotro!
jack
on
the
rear
panel
of
TX-84/82
and
DX-130.
2.5mm
plug
cord
Tape
Deck
and
Graphic
Equalizer
1.
This
unit
has
facilities
for
two
tape
decks.
Only
the
tape
deck
connected
to
the
TAPE-1
jacks.
If
you
have
two
decks,
connect
the
one
to
the
TAPE-1
jacks
and
the
other
deck
to
the
TAPE-2
Jacks.
2.
Connect
the
output
leads
of
the
tape
decks
to
the
TAPE-1
and
TAPE-2
PLAY
jacks.
Connect
the
input
leads
of
the
tape
decks
to
the
TAPE-1
and
TAPE-2
REC
jacks
of
the
unit.
For
more
details,
refer
to
your
tape
deck
instruction
manual.
3.
Toconnect
a
graphic
equalizer
too,
use
the
TAPE-2
jacks
and
connect
the
second
tape
deck
to
the
tape
jacks
of
the
equalizer.
To
connect
a
graphic
equalizer
and
second
tape
deck
to
the
TAPE-2
jacks.
To
TAPE-2
“REC”
jacks
of
TX-84/82
To
TAPE-2
“PLAY”
jacks
of
TX-84/82
Graphic
equalizer
Second
tape
deck
