Onkyo TX-RZ800

33/60 PAGE
1
R1442 CHIP TYPE CARBON RESISTOR RN72K1J-151JE 1 435031514R1
1
R1443 CHIP TYPE CARBON RESISTOR RN72K1J-151JE 1 435031514R1
1
R1444 CHIP TYPE CARBON RESISTOR RN72K1J-151JE 1 435031514R1
1
R1445 CHIP TYPE CARBON RESISTOR RN72K1J-151JE 1 435031514R1
1
R1446 CHIP TYPE CARBON RESISTOR RN72K1J-151JE 1 435031514R1
1
R1447 CHIP TYPE CARBON RESISTOR RN72K1J-151JE 1 435031514R1
1
R1450 CHIP TYPE CARBON RESISTOR RN72K1J-151JE 1 435031514R1
1
R1451 CHIP TYPE CARBON RESISTOR RN72K1J-151JE 1 435031514R1
1
R1452 CHIP TYPE CARBON RESISTOR RN72K1J-151JE 1 435031514R1
1
R1453 CHIP TYPE CARBON RESISTOR RN72K1J-151JE 1 435031514R1
1
R1454 CHIP TYPE CARBON RESISTOR RN72K1J-151JE 1 435031514R1
1
R1455 CHIP TYPE CARBON RESISTOR RN72K1J-151JE 1 435031514R1
1
R1456 CHIP TYPE CARBON RESISTOR RN72K1J-151JE 1 435031514R1
1
R1457 CHIP TYPE CARBON RESISTOR RN72K1J-151JE 1 435031514R1
1
R1460 CHIP TYPE CARBON RESISTOR RN72K1J-472JE 1 435034724R1
1
R1461 CHIP TYPE CARBON RESISTOR RN72K1J-472JE 1 435034724R1
1
R1470 CHIP TYPE CARBON RESISTOR RN72K1J-222JE 1 435032224R1
1
R1471 CHIP TYPE CARBON RESISTOR RN72K1J-222JE 1 435032224R1
1
R1480 CHIP TYPE CARBON RESISTOR RN72K1J-472JE 1 435034724R1
1
R1481 CHIP TYPE CARBON RESISTOR RN72K1J-472JE 1 435034724R1
1
R1490 CHIP TYPE CARBON RESISTOR RN72K1J-472JE 1 435034724R1
1
R1491 CHIP TYPE CARBON RESISTOR RN72K1J-472JE 1 435034724R1
1
R1500 CHIP TYPE CARBON RESISTOR RN72K1J-472JE 1 435034724R1
1
R1501 CHIP TYPE CARBON RESISTOR RN72K1J-472JE 1 435034724R1
1
R1510 CHIP TYPE CARBON RESISTOR RN72K1J-681JE 1 435036814R1
1
R1511 CHIP TYPE CARBON RESISTOR RN72K1J-681JE 1 435036814R1
1
R1520 CHIP TYPE CARBON RESISTOR RN72K1J-102JE 1 435031024R1
1
R1521 CHIP TYPE CARBON RESISTOR RN72K1J-102JE 1 435031024R1
1
R1530 CHIP TYPE CARBON RESISTOR RN72K1J-152JE 1 435031524R1
1
R1531 CHIP TYPE CARBON RESISTOR RN72K1J-152JE 1 435031524R1
1
R1540 CHIP TYPE CARBON RESISTOR RN72K1J-682JE 1 435036824R1
1
R1541 CHIP TYPE CARBON RESISTOR RN72K1J-682JE 1 435036824R1
1
R1550 CHIP TYPE CARBON RESISTOR RN72K1J-152JE 1 435031524R1
1
R1551 CHIP TYPE CARBON RESISTOR RN72K1J-152JE 1 435031524R1
1
R1560 CHIP TYPE CARBON RESISTOR RN72K1J-331JE 1 435033314R1
1
R1561 CHIP TYPE CARBON RESISTOR RN72K1J-331JE 1 435033314R1
1
R1570 CHIP TYPE CARBON RESISTOR RN72K1J-331JE 1 435033314R1
1
R1571 CHIP TYPE CARBON RESISTOR RN72K1J-331JE 1 435033314R1
[SW TRM]
1
P1000 TRM-423(SCREW) NEJITANSI ST3 1 25060495
P1001 ST JACK MSJ-035-22 1 25045887
P1002 PIN JACK NPJ-2PDOO626 1 25045847
1
P1003 TRM-423(SCREW) NEJITANSI ST3 1 25060495
1
P1004 TRM-423(SCREW) NEJITANSI ST3 1 25060495
P1008B PLUG IMSA-9142B-24A 1 25056602
1
P8002B SOCKET(B to B) IMSA-9850S-24Y 1 25052815R2
1
P8003B SOCKET(B to B) IMSA-9850S-24Y 1 25052815R2
[TUNER UNIT]
U1000 PHOTO COUPLER JSR1165-001recieving 1 24120143
U1001 PHOTO COUPLER JSR1165-001recieving 1 24120143
U1002 PHOTO COUPLER JSR1165-001recieving 1 24120143
U006 BADIS-1810-1A : NSP
CIRCUIT NO.
PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[SEMI CONDUCTOR]
1
D7500 ZENER DIODE DZ2J082M0L 1 224760820R2
1
D7501 ZENER DIODE DZ2J039M0L 1 224760390R2
D7502 LED HLMP-Y701 1 225528
1
D7502A HOLDER (LED)LH-5-5 1 27191312
1
D7530 ZENER DIODE DZ2J051M0L 1 224760510R2
1
D7533 ZENER DIODE DZ2J068M0L 1 224760680R2
1
D7534 ZENER DIODE DZ2J068M0L 1 224760680R2
1
D7580 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D7581 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D7582 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D7583 CHIP TYPE DIODE DA2J10100 1 223303R2
D7591 LED SCB3318E-D2 1 225487
