Onkyo TX-RZ800

34/60 PAGE
D7592 LED HLMP-Y701 1 225528
1
D7592A HOLDER (LED)LH-5-5 1 27191312
D7593 LED SCB3318E-D2 1 225487
1
Q1 HYBRID IC RZ5B801-0001E2 1 22242835R2
1
Q7505 TRANSISTOR KTC3875-GR 1 2216175R2
1
Q7511 TRANSISTOR KRC107S 1 2216340R2
1
Q7512 TRANSISTOR KTA1661-Y 1 2217864R2
1
Q7520 HYBRID IC BU2090F-E2 1 22242686R2
1
Q7530 HYBRID IC NJM4580CG 1 22242922R2
1
Q7532 TRANSISTOR RTAN430C-T112-1 1 2217780R2
1
Q7533 TRANSISTOR RN2403 1 2214540R2
Q7561 REMOTE SENSOR IRM-3638M3S28 1 24130026
1
Q7650A HOLDER (FL) 1 27191370
1
Q7650Aor HOLDER (FL) ( 1) 27191303
Q7801 FLUORESCENT TUBE 16-BT-165GINK 1 212276
1
Q7802 TRANSISTOR 2SC2712-GR 1 2213145R2
1
Q7803 TRANSISTOR 2SC2712-GR 1 2213145R2
[TRANS COIL]
1
L1 CHIP TYPE CARBON RESISTOR RN72K1J-000JE 1 435030004R1
1
L2 CHIP TYPE CARBON RESISTOR RN72K1J-000JE 1 435030004R1
1
L3 RF COIL SDCL1608CR33JTDF 1 233557R1
1
L3 or RF COIL HK1608R33J-T ( 1) 233559R1
1
L4 RF COIL SDCL1608CR10JTDF 1 233556R1
1
L4 or RF COIL HK1608R10J-T ( 1) 233558R1
L5 ANTENNA COIL K7-D 1 232212
1
L7530 CHOKE COIL LBC2518T2R2M 1 231364M022R2
1
L7531 CHOKE COIL LBC2518T2R2M 1 231364M022R2
1
L7580 CHOKE COIL LBC2518T2R2M 1 231364M022R2
1
L7581 CHOKE COIL LBC2518T2R2M 1 231364M022R2
1
L7582 CHOKE COIL LBC2518T2R2M 1 231364M022R2
1
L7801 CHOKE COIL LBC2518T2R2M 1 231364M022R2
1
L7802 CHOKE COIL LBC2518T2R2M 1 231364M022R2
X1 CRYSTAL HC-49S 9B12.000MHz 1 3010533
[CAPACITOR]
1
C1 CHIP TYPE CERAMIC CAPACITOR CC725CH1H-101J1 1 342101014R1
1
C12 CHIP TYPE CERAMIC CAPACITOR CC725CH1H-090D1 1 342100902R1
1
C13 CHIP TYPE CERAMIC CAPACITOR CK725B1C-104K1 1 332121045R1
1
C2 CHIP TYPE CERAMIC CAPACITOR CC725CH1H-220J1 1 342102204R1
1
C3 CHIP TYPE CERAMIC CAPACITOR CK725B1H-332K1 1 332103325R1
1
C4 CHIP TYPE CERAMIC CAPACITOR CC725CH1H-100D1 1 342101002R1
1
C5 CHIP TYPE CERAMIC CAPACITOR CK725B1H-473K1 1 332104735R1
1
C6 CHIP TYPE CERAMIC CAPACITOR CK725B1H-222K1 1 332102225R1
1
C7 CHIP TYPE CERAMIC CAPACITOR CK725B1A-105K1 1 332131055R1
1
C7500 CHIP TYPE CERAMIC CAPACITOR CK725B1H-223K1 1 332102235R1
1
C7501 CHIP TYPE CERAMIC CAPACITOR CK725B1H-223K1 1 332102235R1
1
C7502 CHIP TYPE CERAMIC CAPACITOR CK725B1H-223K1 1 332102235R1
1
C7503 CHIP TYPE CERAMIC CAPACITOR CK725B1H-223K1 1 332102235R1
1
C7504 CHIP TYPE CERAMIC CAPACITOR CK725B1H-223K1 1 332102235R1
C7506 ELECTROLYTIC CAPACITOR CE04W16V-47M(S) 1 353744709T
C7508 ELECTROLYTIC CAPACITOR CE04W6.3V-100M(S) 1 353721019T
C7509 ELECTROLYTIC CAPACITOR CE04W16V-10M(S) 1 353741009T
1
C7511 CHIP TYPE CERAMIC CAPACITOR CC725CH1H-101J1 1 342101014R1
1
C7512 CHIP TYPE CERAMIC CAPACITOR CC725CH1H-101J1 1 342101014R1
1
C7513 CHIP TYPE CERAMIC CAPACITOR CC725CH1H-101J1 1 342101014R1
1
C7514 CHIP TYPE CERAMIC CAPACITOR CK725F1E-104Z1 1 332161040R1
1
C7517 TF TYPE PLASTIC FILM CAPACITOR ECQ-V50V-474J 1 374724744T
1
C7517 or FILM C C281H474J20A21A ( 1) 376824744T
1
C7522 CHIP TYPE CERAMIC CAPACITOR CK725F1A-105Z1 1 332181050R1
1
C7525 CHIP TYPE CERAMIC CAPACITOR CC725CH1H-101J1 1 342101014R1
1
C7526 CHIP TYPE CERAMIC CAPACITOR CC725CH1H-101J1 1 342101014R1
1
C7532 CHIP TYPE CERAMIC CAPACITOR CC725CH1H-101J1 1 342101014R1
C7533 ELECTROLYTIC CAPACITOR CE04W16V-47M(S) 1 353744709T
C7534 ELECTROLYTIC CAPACITOR CE04W16V-47M(S) 1 353744709T
C7535 ELECTROLYTIC CAPACITOR CE04W50V-10M 1 355781009T
C7536 ELECTROLYTIC CAPACITOR CE04W16V-47M(S) 1 353744709T
1
C7537 CHIP TYPE CERAMIC CAPACITOR CC725CH1H-330J1 1 342103304R1
C7538 ELECTROLYTIC CAPACITOR CE04W35V-10M(S) 1 353761009T
1
C7539 CHIP TYPE CERAMIC CAPACITOR CK725B1H-104K1 1 332101045R1
1
C7543 CHIP TYPE CERAMIC CAPACITOR CK725F1E-104Z1 1 332161040R1
1
C7544 CHIP TYPE CERAMIC CAPACITOR CK725F1E-104Z1 1 332161040R1
C7561 ELECTROLYTIC CAPACITOR CE04W16V-10M(S) 1 353741009T
