 5.1.4 Channel System
A 5.1.4 Channel System is a speaker layout combining 2 sets of the height speakers, 1 set of left and right at the front and 1 set of left and right at the rear, to the basic
5.1 Channel System ( p19). Installing the height speakers will enrich the sound eld feeling in the upper space. Combination of 2 height speakers can be selected
from following.
❏ Combination example when Top Front
Speakers are used at the front (
p30)
❏ Combination example when Top Middle
Speakers are used at the front (
p32)
❏ Combination example when Front High
Speakers are used at the front (
p33)
❏ Combination example when Dolby Enabled
Speakers (Front) are used at the front
(
p35)
