Part Names
Front
1. Microphone: Used when talking to Amazon Alexa.
2. Preset button: You can tune stations with one press of a
button by registering your favorite stations. (P4)
3. Light Ring: The status of this unit is indicated by the colors
and illumination status of the LEDs. (P3)
4. Mic Mute button: Turn on or off microphone.
0 Amazon Alexa will not respond when you call it while
microphone is off.
5. Volume (i/j) buttons: Use to adjust the volume. You can
adjust the volume between 0 and 30. When you press the
i volume button, the Light Ring lights in a clockwise
direction.
6. Amazon Alexa button: Use to call Amazon Alexa with a
button rather than calling it with your voice.
7. Play/pause (1/;) button: Used for play operations in the
Music app, etc.
Back
8. Power (Í) button: A short press turns the power on or off.
9. Wi-Fi ( ) button:
Wi-Fi setup mode: 8 seconds press
WPS mode: 3 seconds press
Cancel: Single press
10.
RESET button: Use to reset the unit to return it to the state
it was in at the time of shipment. (P4)
11.
micro USB/USB ports: This is not available for use. It is
only used when the unit is being serviced.
12.
AUX IN ( ) jack: Use the supplied mini plug cable to
input the audio from other devices to this unit. (P4)
13.
AUX OUT ( ) jack: Use the supplied mini plug cable to
output the audio received by this unit to another device.
(P4)
14.
DC IN: Connect the supplied AC adapter.
