OPTICAL-IN OPERATION
4. Power on the connected external player and start playing the music as usual.
Turn on the digital audio output and set it to PCM (Pulse Code Modulation) type
similar to the below figure:
Bass
Treble
Balance
Select
Move
MENU
Exit
Sound Mode Standard
Surround Off
AVL Off
Audio Language English
Time
Setup
Lock
Off
AudioAudio
Digital Output PCMDigital Output PCM
1. Connect the Optical out jack from the external audio player (such as TV, DVD
player etc.) to the OPT IN jack on the rear of the unit with the optical connection
cable as illustated below:(For PCM format only)
OPTICAL OUT
Optical Connection Cable
TV or DVD player etc.
16
2. Power on the unit as previously explained.
Rear Panel
AUX IN
LINE IN
L R
OPT IN
DC IN 16V
3. Press the button on the unit or remote control repeatedly or press the
OPTICAL button on remote control to switch to
OPTICAL IN mode, the OPT IN
indicator on the unit will turn Blue.
(not included)
