Opalum® FLOW series
Opalum® STREAM series
Owner's Guide w w w . o p a l u m . c o m
Control Hub color coding
(see section 3. for further information)
The status Indicator
(see section 7. for further information)
Sound Technology 26
2
3 4 5 6 7
8 9
(light blue) Analog input
(yellow) Digital input, coaxial
(pink) Digital input, optical 1
(dark blue) Digital input, optical 2
(green) Wireless streaming (optional)
1
