122 Climate control
Climate control
Climate control systems ............. 122
Air vents ..................................... 130
Maintenance .............................. 130
Climate control systems
Heating and ventilation
system
Controls for:
■ Temperature
■ Air distribution
■ Fan speed
■ Demisting and defrosting
Heated rear window Ü 3 33.
Temperature
red = warm
blue = cold
Heating will not be fully effective until
the engine has reached normal
operating temperature.
Air distribution
s
= to windscreen and front door
windows
M
= to head area via adjustable air
vents
K
= to foot well
All combinations are possible.
Fan speed
Adjust the air flow by switching the fan
to the desired speed.
