Vehicle care 199
No. Circuit
1 Soft top control module, power
rail right
2 –
3 Parking assist
4 –
5 –
6 –
7 Power seat
8 Soft top control module
9 –
10 –
11 Trailer module, tire pressure
monitor and rear view camera
12 Soft top control module, tail
lights
13 –
14 Rear seat electrical folding
15 –
No. Circuit
16 Seat ventilation, rear view
camera, soft top control module
17 –
18 –
19 Steering wheel heating
20 –
21 Seat heating
22 –
23 Soft top control module, power
rail left
24 –
25 –
26 Jumper fuse for non logistic
mode
27 Passive entry
28 –
29 Hydraulic unit
30 –
No. Circuit
31 –
32 Flex Ride
