42 Keys, doors and windows
■ Insert the adapter of the deflector
with the elevation into the opposite
recess of the guidance.
■ Slide deflector in the guidance to
the right vehicle side until it
engages.
■ Raise rear backrest.
Remove deflector in reverse order.
Fitting of the big wind deflector
■ Take the deflector out of the bag.
■ Extract the four locking pins of the
deflector: the upper ones leap out
spring-loaded by turning the pins
out of the brackets on both sides,
the lower ones leap out by lifting the
detents at the sliders on both sides.
■ Expand the wind deflector.
■ With the hinges behind the front
seats insert the right side locking
pins in the recesses of the right side
trim near the rear seat. Fold the
deflector a little at the centre and
insert the left side locking pins in the
recesses of the left side trim. Make
sure that all pins are properly
engaged. Push down the deflector
at the centre.
