Vehicle care 107
3. Disengage spring clip from
retainer by moving it forward and
swivelling to the side.
4. Remove bulb from reflector
housing.
5. When installing the new bulb,
insert lugs in the reflector
recesses.
6. Install spring clip, plug connector
onto bulb.
7. Install protective cover.
Side lights
1. Rotate high beam protective
cover anticlockwise and remove.
2. Detach plug connector from high
beam bulb.
3. Remove bulb from reflector and
renew bulb.
4. Insert bulb socket in reflector.
