a. Legacy ACU (for first gen Smart Hubs)
b. Single Door Controller (SDC)
c. Core Series ACU (for Core Series Smart Hubs)
6. If your ACU also connects to an expansion board (this is most common with
Core Series Smart Hubs), then from the Add Expansion Board dropdown,
select and add the appropriate type(s):
a. Openpath 4-Port Expansion
b. Openpath 8-Port Expansion
c. Openpath 16-Port Elevator
7. A description will appear in green. Click Save.
8. At this point, you can create Readers, Entries, and Zones prior to provisioning
PROVISIONING STEPS
To provision the ACU using the Open Admin app (recommended):
1. Log into the Open Admin app with your Control Center credentials
2. Locate the org to which you’re provisioning hardware, either on the list or using
search, then tap on the org name
3. Press the Admin button on the Controller Board or Core
4. In the Open Admin app, tap on the last four digits of the serial number for the
ACU
5. Tap Test Internet Connection and wait for a green YES to appear before
proceeding with the next step
a. Note: This checks if the ACU/SDC can ping
https://api.openpath.com/health
6. Tap Provision Device
7. Tap on the ACU Name that you want to provision to (this is the name of the
ACU you created in the Control Center), then tap Yes to proceed
8. The app will send notifications when ACU provision state changes from
Unprovisioned to Provisioning in progress to Provisioning complete
a. Note: ACU will disconnect from the Open Admin app 5 minutes after
first pressing the Admin button
To provision the ACU using a laptop:
1. On a computer or mobile phone on the same network as the ACU, go to
https://control.openpath.com and log in
2. Go to Hardware > ACU Management
3. Locate the ACU on the list and click Register
4. A new window will open with instructions on registering the ACU. Click Yes to
proceed.
5. If you don't see your ACU listed, create a new one:
a. Click Add ACU and enter a name
To Next Page
