Oppo PM-3 User Manual


7

Specifications
HeadphoneSpecifications
ModelName PM‐3
AcousticPrinciple Closed‐back
EarCoupling Circumaural
NominalImpedance 26Ohm
Sensitivity 102dBin1mW
ClampingPressure 5N
Cables
3 mdetachablecable(3.5 mm&6.35mm)
1.2mdetachablecable(3.5mm)
CableConnectors
Output:3.5 mmstereo
j
ack
Input:6.35mmstereojack,3.5mmstereojack
Weight 320g(withoutcable)
Accessories
Carryingcase
UserManual

DriverSpecifications
DriverType PlanarMagnetic
DriverSize(Round) 55mmdiameter
MagnetSystem Symmetricpush‐pullneodymium
FrequencyResponse In
Free‐Field
10–50,000Hz
Long‐TermMaxInput
Power
500mWaccordingtoIEC60268‐7
PulseMaxInputPower 2W



Oppo PM-3 Specifications

General

Driver Type	Planar Magnetic
Frequency Response	10 Hz - 50 kHz
Impedance	26 Ohms
Sensitivity	102 dB/mW
Weight	320 g
Cable Length	1.2 m
Connector	3.5 mm
Type	Closed-back
