Opt Lasers TEC-8A-24V-PID-HC - Technical Data

Technical Data
RS232 Programmable
Temperature
Controller ±100°C
(Advanced)
RS232 Programmable
Temperature
Controller
(Advanced)
Temperature
Controller (Basic)
Maximum current
8A
Input Voltage (V LOG)
5 – 24 V
Input Voltage (V TEC)
5 – 24 V
Serial Interface
3.3V Logic, 1 start bit = 0, 8 data bits, no parity, 1 stop bit = 1
Serial Transmission
Yes
Serial Reception
Yes
No
Temperature
Stabilization Accuracy
±2°C*
±2°C
±2°C
Temperature Tracing
Accuracy
±0.05°C
Cooling or heating
work
Yes
Temperature sensor
P0K1.202.3FW.B.007
10k NTC B=3950
Temperature range
Tmin and Tmax
-100 to +100°C
0 to +50°C
0 to +50°C
Heat sink required
No
Dimensions
45 x 60 mm
Mounting holes
37 x 52 mm
Mounting holes
diameter
3.2 mm
* Applicable for the range ±50°C. For the range ±100°C accuracy is ±3°C
