3. Receivers3. Receivers
Receiver InformationReceiver Information
All central station receivers have different types of line cards that are capable of accepting or not accepting certain formats. Therefore it is recommended
that you contact the technical support group at your central station to determine the fastest and most reliable format available.
# Format Name Description
Accepted Receivers
1 10PPS 3-1 10 pulses per second - 3 digit account number - 1 digit report code
Varitech- Ademco SK FBI
2 10PPS 3-1 EXT 10 pulses per second - 3 digit account number - 1 digit report code w/ extended 2 digit
Varitech- Ademco SK FBI
3 10PPS 4-1 10 pulses per second - 4 digit account number - 1 digit report code
Varitech- Ademco SK FBI
4 10PPS 4-1 EXT 10 pulses per second - 4 digit account number - 1 digit report code w/ extended 2 digit
Varitech- Ademco SK FBI
5 10PPS 4-2 10 pulses per second - 4 digit account number - 2 digit report code
Varitech- Ademco SK FBI
6 20PPS 3-1 20 pulses per second - 3 digit account number - 1 digit report code
Varitech- Ademco SK FBI
7 20PPS 3-1 EXT 20 pulses per second - 3 digit account number - 1 digit report code w/ extended 2 digit
Varitech- Ademco SK FBI
8 20PPS 4-1 20 pulses per second - 4 digit account number - 1 digit report code
Varitech- Ademco SK FBI
9 20PPS 4-1 EXT 20 pulses per second - 4 digit account number - 1 digit report code w/ extended 2 digit
Varitech- Ademco SK FBI
10 20PPS 4-2 20 pulses per second - 4 digit account number - 2 digit report code
Varitech- Ademco SK FBI
11 40PPS W/PARITY 40 pulses per second - 3 digit account number - 1 digit report code
Varitech- Ademco SK FBI
12 VAR FSK 4-2 Tones (no pulses) - 4 digit account number - 2 digit report code
Varitech
13 SIA LEVEL 1 Tone (no pulses) - 4 digit account number - zone type w/zone number in English
Check w/central station
14 CONTACT ID Tone (no pulses) - 4 digit account number - zone type w/zone number in English
Check w/central station
Receiver Routing OptionsReceiver Routing Options
The chart below indicates all reporting options in alphabetical order and the individual receiver routing.
Report Codes Menu Rcvr
Routing
Report Codes Menu Rcvr
Routing
2-Wire Smk Alarm 4.6.1 3.8.1. Emergency Report 4.5.2 3.8.3.
2-Wire Smk Restore 4.6.3 3.8.1. Enter Install. Prog 5.2.8 3.8.3.
2-Wire Smk Trbl 4.6.2 3.8.1.
Exit Error 5.2.5 3.8.2.
Abnormal Self Test 1.3.5 3.8.3.
Exit Install. Prog. 5.2.9 3.8.3.
AC Fail 5.1.1 3.8.3. Force Arm 5.3.7 3.8.2.
AC Restore 5.1.2 3.8.3. Ground Fault 5.3.6 3.8.3.
Auto Arm Code 8.3.2 3.8.2.
No Trip Code 2.8 3.8.3.
Auto Arm Fail 8.3.3 3.8.2.
O/C Buffer Full 5.3.1 3.8.2.
Aux. Power Fail 5.3.4 3.8.3. O/C Buffer Over 5.3.2 3.8.2.
Aux. Power Restore 5.3.5 3.8.3. On Premise Arm 5.3.8 3.8.2.
Battery Low 5.1.3 3.8.3. Open Code (all) 6.4.1 3.8.2.
Battery Restore 5.1.4 3.8.3. Open Code (user) 6.4.3 3.8.2.
Bell Fault Restore 5.1.8 3.8.3. Open Exception 5.2.6 3.8.2.
Bell Fault Trouble 5.1.7 3.8.3. Open Restore 5.2.4 3.8.2.
Bell Restore 5.2.3 3.8.3.
Self Test 1.3.4 3.8.3.
Box Tamper 5.1.5 3.8.3. Special PIN 5.3.9 3.8.3.
Box Tamper Restore 5.1.6 3.8.3.
TLM Fault 3.7.1 3.8.3.
Bus Fault 5.2.1 3.8.3.
TLM Restore 3.7.2 3.8.3.
Bus Restore 5.2.2 3.8.3. Unauthorized User 5.3.3 3.8.3.
Close Code (all) 6.4.2 3.8.2.
Zone Alarm 2.3.1 3.8.1
Close Code (user) 6.4.4 3.8.2.
Zone Bypass 2.3.3 3.8.1
Close Exception 5.2.7 3.8.2.
Zone Cancel 2.3.4 3.8.1
Comm Fail 3.6 3.8.3. Zone Restore 2.3.5 3.8.1
Duress 5.1.9 3.8.3. Zone Trouble 2.3.2 3.8.1
Legend 3.8.1 = Alarm Codes / 3.8.2 = Open\Close Codes / 3.8.3 = System Codes
