Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839 SMDC-16 Program Manual 3440-0252 A4
4. System Options4. System Options
This section determines the various options that are available for Monitor Mode,
Walk Test, System Features, System Messages, Emergency, 2 Wire Smoke and
Force Arming capabilities. Within each of these sub-menus, select the necessary
options that are required for the installation.
4.1. Monitor Mode4.1. Monitor Mode
Note:Note: see chart on page 29 for detailed operation.
4.1.1 Ack Required
ACKNOWLEDGE
NO 0=NO 1=YES
Selections: Yes / No
Default: No
Enable to option if the outputs assigned to Monitor will be continuous or monetary
(monetary if Ack = no / continuous if Ack = yes)
4.1.2 Scroll Open Zones
SCROLL OPEN
NO 0=NO 1=YES
Selections: Yes / No
Default: No
Enable this option for the non-secure zones will scroll on the keypad(s).
4.1.3 Scroll Bypass Zones
SCROLL BYPASS
NO 0=NO 1=YES
Selections: Yes / No
Default: No
Enable this option for the keypads to scroll all bypassed zones while the SMDC
is in the Monitor mode. (see 2.7.4 Bypass Allowed).
4.1.4 Silent Monitor Mode
SILENT MODE
NO 0=NO 1=YES
Selections: Yes / No
Default: No
Enable this option for all of the installed keypads to be silent in the Monitor mode.
4.1.5 Auto Monitor on Disarm
MON ON DISARM
NO 0=NO 1=YES
Selections: Yes / No
Default: No
Enable this option for the SMDC to be automatically placed in the Monitor Mode
upon disarming.
Note:Note: This option will not function if an alarm condition has taken place during the
armed state.
4.1.6 PIN Entry Required
PIN REQUIRED
NO 0=NO 1=YES
Selections: Yes / No
Default: No
Enable this option if the installation requires that an authorized user PIN be used to enter
the Monitor Mode.
NoteNote: This option should be set for yes if the keypad will be installed in a public access area.
4.1.7 Monitor Outputs
This sections determines which output(s) will activate when a zone is activated during
the Monitor Mode (see 2.7.8 Monitor).
4.1.7.1 Bell 1
BELL OUTPUT 1
NO 0=NO 1=YES
Selections: Yes / No
Default: No
Enable this option for the SMDC to activate the Bell 1 output when a Monitor Mode
zone is activated. (see 4.1.1 Ack Required).
1. Monitor Mode
1. Ack Required
2. Scroll Open Zones
3. Scroll Bypass
4. Silent Mon. Mode
5. Auto Mon on Disarm
6. PIN Entry Required
7. Outputs
1. Bell 1
2. Bell 2
3. Relay 1
4. Relay 2
5. PGM 1
6. PGM 2
7. PGM 3
2. Walk Test Mode
1. Bell 1
2. Bell 2
3. Relay 1
4. Relay 2
5. PGM 1
6. PGM 2
7. PGM 3
3. System Features
1. Hist. View by User
2. O/C View by User
3. Silent Trouble
4. Not Used - Reserved
5. 50Hz/60Hz
6. AC/Crystal
7. Pwr Dly Time
8. PIN Require for Scan
9. Threshold Bad Codes
4. System Messages
1. Top Line Display
1. Grp/Part 1 Display
7-8. Group/Part Display
2. Disarmed Nml Msg
3. Disarmed Abnml Msg
5. Emergency
1. Emergency Enabled
2. Emergency Rpt
3. Bell 1 Output
4. Bell 2 Output
5. Relay 1 Output
6. Relay 2 Output
7. PGM 1 Output
8. PGM 2 Output
9. PGM 3 Output
6. 2 Wire Smk
1. Alarm Report
2. Trouble Report
3. Smoke Restore
4. Smoke Reset
5. Alarm Verify
6. Outputs
1. Bell 1 Output
2. Bell 1 Pulse
3. Bell 2 Output
4. Bell 2 Pulse
5. Relay 1 Output
6. Relay 2 Output
7. PGM 1 Output
8. PGM 2 Output
9. PGM 3 Output
7. Force Arming Enabled
8. PGM / INP Functions
1. PGM 1 Function
2. PGM 2 Function
3. PGM 3 Function
