Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839 SMDC-16 Program Manual 3440-0252 A4
4. System Options4. System Options
4.8. PGM / INP Functions (continued)4.8. PGM / INP Functions (continued)
4.8.2 PGM 2 Functions
PGM-2 FUNCTION
NO
Selections: 01- 40
Default: No
Select one of the options from the PGM list on page 37. (see wiring diagram).
4.8.3 PGM 3 Functions
PGM-3 FUNCTION
NO
Selections: 01- 40
Default: No
Select one of the options from the PGM list on page 37. (see wiring diagram).
4.8.4 Auxiliary Input 1
INP-1 FUNCTION
NO
Selections: 00 - 10
Default: no
Select one of the options from the Input list on page 37. (see wiring diagram).
4.8.5 Auxiliary Input 2
INP-2 FUNCTION
NO
Selections: 00 - 10
Default: no
Select one of the options from the Input list on page 37. (see wiring diagram).
4.8.6 LED 1 Function
LED-1 FUNCTION
NO
Selections: 00 - 40
Default: no
Select one of the options from the PGM list on page 37 to allow LED 1 output to
operate as PGM output. (see wiring diagram).
4.8.7 LED 2 Function
LED-2 FUNCTION
NO
Selections: 00 - 40
Default: no
Select one of the options from the PGM list on page 37 to allow LED 2 output to
operate as PGM output. (see wiring diagram).
4.8.8 Radio Transmit Function
R-TX FUNCTION
NO
Selections: 00 - 40
Default: no
Select one of the options from the PGM list on page 37 to allow Radio TX output to
operate as PGM output. (see wiring diagram).
4.8.9 Radio Key Function
R-KEY FUNCTION
NO
Selections: 00 - 40
Default: no
Select one of the options from the PGM list on page 37 to allow Radio Key output to
operate as PGM output. (see wiring diagram).
4.9. Temporal Fire
TEMPORAL FIRE
NO 0=NO 1=YES
Selections: Yes / No
Default: No
Enable this option to allow for a unique output to be presented on the Fire bell voltage
circuit. The output cycle will be:
1/2 second on
1/2 second off
1/2 second on
1/2 second off
1/2 second on
2 1/2 second off
and will repeat the above cycle until the bell cutoff time has expired.
(see 1.2 Cut Off Times)
1. Monitor Mode
1. Ack Required
2. Scroll Open Zones
3. Scroll Bypass
4. Silent Mon. Mode
5. Auto Mon on Disarm
6. PIN Entry Required
7. Outputs
1. Bell 1
2. Bell 2
3. Relay 1
4. Relay 2
5. PGM 1
6. PGM 2
7. PGM 3
2. Walk Test Mode
1. Bell 1
2. Bell 2
3. Relay 1
4. Relay 2
5. PGM 1
6. PGM 2
7. PGM 3
3. System Features
1. Hist. View by User
2. O/C View by User
3. Silent Trouble
4. Not Used - Reserved
5. 50Hz/60Hz
6. AC/Crystal
7. Pwr Dly Time
8. PIN Require for Scan
9. Threshold Bad Codes
4. System Messages
1. Top Line Display
1. Grp/Part 1 Display
7-8. Group/Part Display
2. Disarmed Nml Msg
3. Disarmed Abnml Msg
5. Emergency
1. Emergency Enabled
2. Emergency Rpt
3. Bell 1 Output
4. Bell 2 Output
5. Relay 1 Output
6. Relay 2 Output
7. PGM 1 Output
8. PGM 2 Output
9. PGM 3 Output
6. 2 Wire Smk
1. Alarm Report
2. Trouble Report
3. Smoke Restore
4. Smoke Reset
5. Alarm Verify
6. Outputs
1. Bell 1 Output
2. Bell 1 Pulse
3. Bell 2 Output
4. Bell 2 Pulse
5. Relay 1 Output
6. Relay 2 Output
7. PGM 1 Output
8. PGM 2 Output
9. PGM 3 Output
7. Force Arming Enabled
8. PGM / INP Functions
1. PGM 1 Function
2. PGM 2 Function
3. PGM 3 Function
