Optex SMDC-16 Programming Manual

Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839 SMDC-16 Program Manual 3440-0252 A4
1.1 Delay Times1.1 Delay Times
1.1.1 Pre-Alarm Delay
PREALARM DELAY
00 SECONDS
Selections: 0-255 sec.
Default: 0 seconds.
Select the amount of time for silent entry delay.
Note:Note: This value of time will add on to the total entry delay time.
ExampleExample: 15 sec. Pre Alarm Delay + 15 sec. Entry Delay = 30 sec. Ttl Entry Delay
(see 1.1.2-Entry Delay / 2.1.6-Zone Entry Delay).
1.1.2 Entry Delay
ENTRY Delay
00 SECONDS
Selections: 0-255 sec.
Default: 45 seconds
Select the required entry delay.
Note:Note: (see 2.1.6-Entry Delay to customize the entry time by zone).
1.1.3 Exit Delay
EXIT DELAY
00 SECONDS
Selections: 0-255 sec.
Default: 60 seconds.
Select the required exit delay time.
Note:Note: This exit delay is common to all exit zones and cannot be customized by zone.
1.1.4 AC Fail Delay
AC FAIL DELAY
00 x 10 MINUTES
Selections: 0-99 x 10 Minutes.(16.5 hrs. max)
Default: 360 minutes (6 hrs)
Select the amount of time the panel will wait before transmitting the AC Fail Report code
to the central station.
Note:Note: This delay is for communications only, not display.
(see 1.1.5-AC Fail Display / 5.1.1-AC Fail Report Code).
1.1.5 AC Fail Display
AC Fail Display
YES 0=NO 1=YES
Selections: Yes / No
Default: Yes
Enable this option to allow the SMDC to display audibly and visually the AC Fail message
at all keypads.
Note: Note: A PIN is required to be entered to silence this warning indicator.
Note:Note: The AC Fail Display message will occur at all keypads approximately 10 seconds after
the AC fault has occurred.
1.2 Cutoff Times1.2 Cutoff Times
Cutoff times allow for the customizing of the trigger outputs. These outputs maybe used
for a variety of purposes. (see 2-Zone Config. / 3.3-Tel. Monitor / 4.5-Emergency/Duress
/ 4.6-Two Wire Smokes / Wiring diagram).
1.2.1 Bell 1 Cutoff
BELL 1 CUTOFF
10 MINUTES
Selections: 0-99 minutes.
Default: 10 minutes
Select the amount of time in minutes alarm output voltage will be present for Bell 1 output.
1.2.2 Bell 2 Cutoff
BELL 2 CUTOFF
10 MINUTES
Selections: 0-99 minutes.
Default: 10 minutes.
Select the amount of time in minutes alarm output voltage will be present for Bell 2 output.
