5.1 Microscopy environment
 Thismicroscopeisrecommendedtobeusedinaclean,dryandshockfreeenvironmentwithatem-
peratureof0-40°Candamaximumrelativehumidityof85%(noncondensing).Useadehumidierif
needed.
5.2 Before and after using the microscope
- Themicroscopeshouldalwaysbekeptverticallywhenmovingitandbecarefulsothatnomoving
parts, such as the eyepieces, fall out.
- Never mishandle or impose unnecessary force on the microscope.
- Never attempt to service the microscope yourself.
- Afteruse,turnoffthelightimmediately,coverthemicroscopewiththeincludeddust-cover,andkeep
it in a dry and clean place.
5.3 Precautions for a safe use
- Beforeplugginginthepowercordwiththesupply,makesurethatthesupplyingvoltageofyourregion
matcheswiththeoperationvoltageoftheequipmentandthatthelampswitchisinoff-position.
- Donotturnthepoweronandoff,offandonimmediatelyasthiswillshortenthelifespanofthebulb
and may cause damage to the electrical system.
- Users should observe all safety regulations of the region. The equipment has acquired the CE safety
label.However,usersdohavefullresponsibilitytousethisequipmentsafely.
5.4 Cleaning the optics
- Iftheopticalpartsneedtobecleanedtryrstto:usecompressedair.
- Ifthatisnotsufcient:useasoftlint-freepieceofclothwithwaterandamilddetergent.
- Andasanaloption:usethepieceofclothmoistenedwitha3:7mixtureofethanolandether.
 Note:ethanol and ether are highly ammable liquids. Do not use them near a heat source, near
sparksornearelectricequipment.Usethesechemicalsinawellventilatedroom.
- Remembertoneverwipethesurfaceofanyopticalitemswithyourhands.Fingerprintscandamage
the optics.
- Do not disassemble objectives or eyepieces in attempt to clean them.
If you need to send the microscope to Optika for maintenance, please use the original packaging.
5.0 MAINTENANCE
Description: Teaching and routine laboratory microscope.
Die-castmetalstand,withgreatstabilityandergonomics,intendedfortransmittedlight
observation.
Illumination: Lightsource:X-LEDtypewithwhiteLED;brightnessadjustmentthroughapotentiome-
ter placed in the bottom right side of the stand.
LEDpower3W,comparableto30-35Whalogenlamp.
Average LED lifetime about 50.000 hours.
Thecollectinglensoftheilluminatorcanaccommodateadditionallters(blue,yellow,
frosted).
Inputvoltage:110/230Vac,50/60Hz,0,4/0,8A;Fuse:F2A250V
Maximumpower:7W
Observation
modes:
Brighteld,darkeld,phasecontrast,uorescence
Focus: Coaxialcoarseandne(graduated,0.002mm)focusingsystem,withfocusingstop
mechanism (to prevent the objective from hitting the slide).
Focus knobs tension is adjustable.
Stage: Doublelayerwithmechanicalslidingstage,dimensions160x142mm,mo¬vingran-
ge76x52mm.Withsampleholderfortwoslides.
Vernierscalewith0.1mmprecisiononbothtranslationaxis.
Nosepiece: Revolvingnosepiecewith4or5positions,withball-bearingmovement.
Head: Binocular or trinocular, 30° inclined and 360° rotating.
Diopter adjustment on both eyepieces.
Interpupillary adjustment range: 55-75 mm.
Eyepieces: Wideeldeyepieceswith20mmeldnumber.
Objectives: Achromatic set (160mm tube length):
-) 4X/0.10, 10X/0.25, 40X/0.65, 100X/1.25 (oil immersion)
PlanAchromatic set (160mm tube length):
-) 4X/0.10, 10X/0.25, 40X/0.65, 100X/1.25 (oil immersion)
E-PlanAchromaticIOSset(innity-corrected,45mmparfocaldistance):
-) 4X/0.10, 10X/0.25, 40X/0.65, 100X/1.25 (oil immersion)
PlanAchromatic Phase Contrast set (160mm tube length):
-) 4X/0.10, 10X/0.25Ph, 40X/0.65Ph, 100X/1.25Ph (oil immersion)
E-PlanAchromaticIOSPhaseContrastset(innity-corrected,45mmparfocaldistance):
-) 10X/0.25Ph, 20X,0.40Ph, 40X/0.65, 100X/1.25Ph (oil immersion)
PlanAchromaticDarkeldset(160mmtubelength):
-)4X/0.10,10X/0.25,40X/0.65,100X/1.25withiris(oilimmersion)
Allopticstreatedwithanti-fungussystem.
Condenser: Abbecondenser,N.A.1,25withcenteringsystem.
Phasecontrastcondenser(for10X,40X,100Xobjectives),brighteldanddarkeld.
Phasecontrastcondenser(for10X,20X,40X,100Xobjectives)andbrighteld.
Darkeldcondenserforoilimmersion,N.A.1,36withbuilt-inX-LED.
Dimensions: HEIGHT:445mm(withoutattachment)/520mm(withattachment).
WIDTH: 205 mm
DEPTH: 375 mm
WEIGHT: 4 Kg
Accessories: User manual and dust cover included.
