OPTIMA® ORANGETOP™ User Manual
Technical Specifications
Warranty and Warranty Restrictions
Product Registration: Please register your purchase at www.optimabatteries.com, at the
“Register Battery” link.
Every OPTIMA® Lithium battery we make has safeguards. However, please be aware that if you
leave the battery in a deeply discharged state for an extended period, the battery could stop
working permanently due to over-discharge. Over-discharge is not a defect covered by warranty.
OPTIMA® Lithium Technical and Warranty Support
- In the event you need technical or warranty support, please call OPTIMA® Batteries
customer service at 1-888-867-8462 between 9 a.m.-5 p.m. (CST) Monday through Friday,
or via email at info@optimabatteries.com
- All batteries returned to OPTIMA® must first be authorized by OPTIMA® and receive
a RMA#. Units returned without an RMA# may be misplaced or delayed.
LIMITED WARRANTY - OPTIMA® (the “Manufacturer”) warrants this battery (the “product”)
for two years from the date of original purchase at retail against defects in material or
workmanship that may occur under normal use and care.
If the product is not free from defects in material or workmanship, the Manufacturer’s
obligation under this warranty is solely to repair or replace your product with a new or
reconditioned product, at the option of the Manufacturer. It is your obligation to send
the product, along with a copy of the original purchase receipt, postage prepaid to the
Manufacturer, in order for repair or replacement to occur. Hand-written receipts will not be
accepted. This limited warranty is not transferable to subsequent purchasers.
THIS LIMITED WARRANTY IS VOID IF THE PRODUCT OR INCLUDED ACCESSORIES
ARE MISUSED, ABUSED, SUBJECTED TO CARELESS HANDLING, OPENED, REPAIRED,
ALTERED, MODIFIED, OR IF THIS PRODUCT IS RESOLD THROUGH AN UNAUTHORIZED
RETAILER OR THIRD-PARTY. LIMITED WARRANTY DOES NOT COVER:
- Changes to internal resistance or capacity due to aging, cycling or normal wear/use
- Batteries used in deep cycling, as a power source of propulsion of electric vehicles
(such as electric bikes, go-karts, forklifts, golf carts, ride-on toys), or “total loss” systems
- Incidental or other damage due to defective or inadequate vehicle/system voltage
regulation, wiring errors such as arcing, short circuit, etc. or electrical issues caused
by the vehicle
- Cosmetic damage
- Damage occurring during shipping or mishandling. Shipping damage is the responsibility
of the shipping company and should be addressed through them (UPS, FedEx, etc.)
- Physical damage arising from drop, impact, puncture, cracks or heat/melting from an
external heat source
- Exceeding temperature, voltage or current specifications outlined in User Manual
- Corrosion or environmental damage such as exposure to liquids or corrosive environments,
fire, chemicals, fuel, salt water, dirt or debris. This includes exposure or damage resulting
from improper maintenance or cleaning of the battery.
- Batteries used with a battery charger or charging profile that does not meet specifications
outlined in User Manual. Do not use battery chargers, maintainers or charging profiles for
lead acid batteries.
- Improper installation such as loose, over-torqued or incorrect terminal connections;
improper or inadequate cable gauge; improperly securing the battery; incorrectly installing
fitment spacers; exposure to excessive heat or inadequate air flow; improper use or
installation via POWERLINK™ plug or connectors.
- Leaving the battery in a deeply discharged state (below 8 volts) for an extended period
resulting in over-discharge.
MODEL QUAD7 QUAD12 QUAD14 QUAD16 QUAD20 QUA30
Capacity - Nominal (Ah) 3 4.5 7 8 9 15
Operating/Discharge Temperature
Limits
14°F to 140°F (-10°C to 60°C)
Charging Temperature Limits 23°F to 140°F) (-5°C to 60°C)
Recommended Storage
Temperature
32°F to 77°F (0°C to 25°C)
Recommended Storage Voltage 14V
Charging Voltage - Max 14.9V
Voltage at 100% Charge 14.4V
Charging Current - Max via
POWERLINK (A)
3.5A
Charging Current - Max
continuous via terminals (A)
20A 25A 35A 40A 45A 60A
Starting Current - Max (A) 190 380 420 480 540 800
Length - inch (mm)
4.45
(113)
5.24
(133)
5.91
(150)
5.91
(150)
6.89
(175)
6.54
(166)
Width - inch (mm)
2.56
(65)
2.72
(69)
2.72
(69)
3.43
(87)
3.19
(81)
4.92
(125)
Height - inch (mm)
3.41
(86.5)
3.66
(93)
5.12
(130)
5.71
(145)
6.1
(155)
6.69
(170)
Weight lb (kg)
1.7
(0.75)
2.2 (1.0)
3.0
(1.35)
3.6
(1.65)
4.0
(1.82)
7.1 (3.2)
LITHIUM
